6,300 liter order number 60669 Pressure ratings: Internal -1/6 Bar @ -25/+200°C total volume 8,190 liters; Jacket rated -1/6 Bar @ -25/+200°C total volume 795 liters. Lined with glass WWG9115 With a top mounted drive with Burgmann mechanical seal type M462L-D20 and Burgmann Thermosyphon TS 2000 pneumatic bottom outlet valve, and solids dosing device,

UNUSED

Internal finish 240 grit buff polished-Bright polished, external buff polish to a matte finish. ASME NB rated, and "U" stamped.

welded dish heads (2:1) 12 mm thick

Coil: 114 mm OD x 4 mm thick,

Limpet covers bottom dish and 2615 mm of straight side (pitch 150mm). Coil heating surface area.

With Insulation rings and upper drip ring. Two top lifting lugs and one tailing lug.

20" Manhole with Cover and davit arm assist, one 6" sight glass, Support Type: Lugs.

Shell rated 150/FV @ 450 degrees F. Conventional jacket 150/FV @ 450 degrees F with welded 2:1 elliptical heads Alloy mixer with dual tier agitation, lower is a CBT, upper is a PBT

• sanitary reactor body/kettle.
• Wall thickness: 0.25" thick side wall, 0.220" thick top head, 0.218" thick bottom head
• Sanitary construction, vessel and jacket are insulated and covered with a SS shroud.
• Previously used for creams and lotions processing.
• Jacket Thickness 13 Gauge. Support Type: Legs.

• Rated for lethal service.
• Nozzles with Inconel 625 inlay.
• Glasslined beavertail baffle with WIKA TR-10 & PT100 temperature probes.
• Mechanically sealed agitator: FlowServe MD-200 DN140.
• See sales comments for additional options.

• This is a bare reactor

jacketed high pressure reactor Jacket volume: 1700 liter Total length: 8000 mm Jacket wall thickness: 30 mm

MFR # 12269 Model SA-3000 Special three top lifting lugs, six leg couplings, four side wall lugs Shell=1 & 1/64", heads=1 & 1/64", jacket =5/8" PTE size 10 drive with an EX proof 20 HP motor and a dry seal. 36" main cover. 18" man way with pro ring and sight glass assembly with man way assist.

Auft # 37387 belt driven by LOHER 3.6 KW, 1715 RPM, 3/7.7-13.3A/60Hz/220-380 volt motor, ex proof (T3). Designed to German TUV standards. Reglassed in Romani by UGE 2001.

• Can be equipped with Agitation System
• Reglassed KC series reactor body
• Manufacturers number 4364421
• With (4) side support lugs or (8) leg couplings for mounting/installation.

• Sanitary insulation shroud of 304 SS stainless steel.
• Marine style impellor with digital level sensor and digital indicator.
• Pneumatic Harvest Valve.
• Ports for Nutrients inlet & Outlet, sampling, pH, DO, & Temperature control, and other controls.
• Agitator shaft & Impeller is 316 SS. CIP: Yes. Support Type: Legs.

• Intended use: high temperature reactor for adhesives and viscous materials
• Head thickness: 18mm
• Jacket thickness: 16mm with a Cyclo drive gear reducer, Model VM40-62, ratio 29 to 1, input 1200 - 300 RPM, 26 - 14 KW. Direct coupled to a 26/14 KW motor, 6/24 phase, 60 hertz, 440 volt. Final output 41/10 rpm.
  Mechanical seal on shaft, wide sweep gate style agitator designed for viscous applications. Approx. 6" diameter Heating ring in bottom of vessel.
• Heating ring: approx. 6" diameter in bottom of vessel

• Turbines: (1) 4 blade pitched paddle turbine, (1) 4 blade flat disk turbine

Three turns schedule 10 half pipe on bottom head, Eight turns schedule 10 half pipe on side walls. Mixing by Eastern model FRG-C2M with double mechanical seal Duel sets of four blade pitch turbine mixers

• This is a base reactor body.

• Glass type: 3008High fire polish with several plugs visible

• Complete assembly
• Series: RA15 HP flange mount motor

internal pressure 80 bar @ 230 deg C (4174ltr), jacket 20 bar @ 230 deg C (147ltr), 40mm thick straight side, 28mm thick top and bottom

(1) 167ltr 316L s/steel (1.4571) reactor, manufactured by Weigand & Wisser, fabrik #65, internal pressure 6 bar @ 120 deg C, jacket 8 bar @ 120 deg C, bolt dished top, weld dished bottom, 500mm diameter x 570mm straight side, 304 s/steel (1.4301) half pipe coil jacket, Ekato type PM-242 agitator drive, driven by 0.55 kw, 1390 rpm motor, openings top: 1-100mm, 1-80mm, 3-25mm, straight side: 1-25mm, 1-25mm (jacket), bottom: 1-25mm, 1-25mm (jacket), mounted on (2) lugs.

(1) 8.7 sqm c/steel tube, and shell vertical heat exchanger, manufactured by Weigand & Wisser, fabrik #67, pressure tube side 20 bar @ 300 deg C (62ltr), shell 20 bar @ 300 deg C (125ltr), (31) 30mm diameter x 2.5mm x 4m long c/steel tubes, shell 273mm diameter x 4245mm overall length, expansion bellows, (no heads), openings shell side 1-80mm, 1-50mm, mounted on (2) lugs.

(1) 60 sqm 316L s/steel tube, shell and head vertical heat exchanger, manufactured by Huls, fabrik #1201, pressure tube side: 83 bar @ 230 deg C (365ltr), shell 20 bar @ 230 deg C (538ltr), (139) 25mm diameter x 2.5mm x 6642mm long 316L s/steel tubes, 316L s/steel shell 457mm diameter x 7430mm overall length, expansion bellows, (2) 316L s/steel coned heads, (15) internal 316L s/steel baffle plates, openings tubeside: top head with 1-250mm, bottom head with 1-200mm, shell: 2-200mm, mounted on (2) lugs.

(1) 117 sqm c/steel tube shell and head vertical heat exchanger, manufactured by Weigand & Wisser, fabrik #68, pressure tube side 4 bar @ 100 deg C (570ltr), shell 20 bar @ 300 deg C (750ltr), (196) 25mm diameter x 2.5mm x 7.5m long tubes, shell 500mm diameter x 8235mm overall length, expansion bellows, (1) bonnet head, (1) dished head, openings tubeside bonnet head with 2-200mm, dished head with no openings, shell 1-200mm, 1-150m, mounted on lugs.

(1) 495ltr 316L s/steel (1.4571) vertical pressurel tank, manufactured by Metatec Gmbh, fabrik #8828/2, pressure -1/8 bar @ 100/20 deg C, weld dished top and bottom, 700mm diameter x 1124mm straight side, mounted on legs.

(1) 351 m3/hr @ 30 m hd 316L s/steel centrifugal pump, manufactured by Bieri Pumpenbau AG, fabrik #73/1146/9, type BM340/200/1, mechanical seal, driven by 55 kw, 3/50/500 volt, 1475 rpm Exd3nG4 motor, mounted on baseplate.

(1) 199.8 m3/hr @ 28 m hd c/steel centrifugal pump, manufactured by Bieri Pumpenbau AG, fabrik #73/121000002, type BM340/150/1, mechanical seal, driven by 37 kw, 3/50/500 volt, 1465 rpm Exd 3nG4 motor, mounted on baseplate.

(1) centrifugal pump, (1) Lewa diaphragm pump,(1) 1500ltr c/steel horizontal pressure tank, manufactured by Weigand & Wisser, fabrik #69, pressure 20 bar @ 300 deg C, 1m diameter x 1480mm straight side, weld dished ends, openings top: 1-500mm manway, 1-50mm, 2-25mm, 1-end with 2-25mm, 1-end with no openings, bottom: 1-250mm, 1-200mm, mounted on (4) lugs with legs.All parts TUV certified

• This is a base reactor

• Shell=1 & 1/8", Heads=1.125", jacket=0.75".
• PTFE dip tube.
• 24" man way with pro ring and man way assist. With sight glass assembly.
• This is a base reactor

• RA series

No motor drive system only.

• Man way with 4" sight glass, protection ring and assist.

• This is a Base reactor
