Alloy 20 Heads/Carpenter 20 Tubes/ Alloy 20 tube sheet/ CS shell, TEMA Type N.E.M Shell has (4) 3/8" thick baffles.
Type: Heat Exchanger
Subtype: Shell and Tube
Manufacturer: Atlas
Condition: Used
Orientation: Vertical
Shell Pressure: 12.1 bar (175 psi)
Tubes rated -20f @ FV/150 psi, Shell rated -20f @ FV/175 psi
Shell Temperature: 190.6 °C (375 °F). Tube Pressure: 10.3 bar (150 psi). Tube Temperature: 190.6 °C (375 °F). Vacuum: Yes.
Type: Heat Exchanger
Subtype: Shell and Tube
Manufacturer: Atlas
Condition: Used
Material: Stainless Steel 316
Heat Transfer Surface Area: 10.9 m² (117 ft²)
Orientation: Vertical
TEMA type BEM
Shell Pressure: 10.3 bar (150 psi). Shell Temperature: 232.2 °C (450 °F). Shell Material: Carbon Steel. Tube Pressure: 10.3 bar (150 psi). Tube Temperature: 232.2 °C (450 °F). Tube Material: Stainless Steel 316. Tubesheet Material: Stainless Steel 316. Vacuum: Yes. Shell Diameter: 273.1 mm (10.8 in). Head Material: Stainless Steel 316. Length: 2,413 mm (95 in). Tube Type: Straight Tube. Tube Number: 76. Tube Diameter: 19.1 mm (0.75 in). Tube Length: 2,413 mm (95 in). Tube Thickness: 1.52 mm (0.06 in). Nozzle Schedule: - Nozzles: Two 8" nozzles, Two 2" nozzles, One 4" vent, Two 0.75" drains .
Type: Heat Exchanger
Subtype: Shell and Tube
Manufacturer: Atlas
Condition: Used
Material: Carbon Steel
Heat Transfer Surface Area: 2.6 m² (28 ft²)
Orientation: Horizontal
(5) 1/4" thick baffles in shell TEMA type BEM
Shell Pressure: 10.3 bar (150 psi). Shell Temperature: 232.2 °C (450 °F). Shell Material: Carbon Steel. Tube Pressure: 10.3 bar (150 psi). Tube Temperature: 232.2 °C (450 °F). Tube Material: Carbon Steel. Tubesheet Material: Carbon Steel. Vacuum: Yes. Shell Diameter: 228.6 mm (9 in). Head Material: Carbon Steel. Length: 4,140 mm (163 in). Tube Type: Straight Tube. Tube Number: 9. Tube Diameter: 25.4 mm (1 in). Tube Length: 3,632 mm (143 in). Tube Thickness: 2.5 mm (0.1 in). Nozzle Schedule: - Inlets: One inlet 4", three inlets/outlets 2" - Vents & Drains: Four are 3/4"..
