Graphite Carbone of America Corp K 110/35 Shell and Tube Heat Exchanger - IPP# 213102

Type: Heat Exchanger

Subtype: Shell and Tube

Manufacturer: Carbone of America Corp

Model: PYT50-364-22

Condition: Unused

Material: Graphite

Heat Transfer Surface Area: 420 m² (4,521 ft²)

Orientation: Vertical

polytube graphilor heat exchanger Tube sheets Face to face is 23' 9"

Tube Pressure: 5.2 bar (75 psi). Tube Temperature: 176.7 °C (350 °F). Vacuum: Yes. Shell Diameter: 1,270 mm (50 in). Tube Diameter: 38.1 mm (1.5 in). Nozzle Schedule: (1) 28" opening , (1) 6" nozzle on end , (1) 3" nozzle on end section of head, (1) 6" nozzle on end section, (5) 4" nozzles on end section of head..

Type: Heat Exchanger

Subtype: Shell and Tube

Manufacturer: VICARB

Condition: Used

Material: Graphite

Heat Transfer Surface Area: 3 m² (32.3 ft²)

Orientation: Horizontal

Shell Pressure: 3.5 bar (50.8 psi). Shell Temperature: 160 °C (320 °F). Shell Material: Carbon Steel. Tube Pressure: 3.5 bar (50.8 psi). Tube Temperature: 71.1 °C (160 °F). Tube Material: Graphite. Shell Diameter: 285 mm (11.2 in). Length: 2,310 mm (90.9 in). Tube Number: 24. Tube Diameter: 32 mm (1.26 in). Tube Length: 1,790 mm (70.5 in). Tube Thickness: 12 mm (0.47 in). Nozzle Schedule: - Tube Side Openings: (1) 50 mm, (1) 100 mm - Shell Side Openings: (2) 100 mm, (1) 25 mm.

Type: Heat Exchanger

Subtype: Shell and Tube

Manufacturer: VICARB

Condition: Used

Material: Graphite

Heat Transfer Surface Area: 3 m² (32.3 ft²)

Orientation: Horizontal

condenser Tube dimensions: (24) 20mm x 32mm OD x 1790mm long

Shell Pressure: 3.5 bar (50.8 psi). Shell Temperature: 160 °C (320 °F). Shell Material: Carbon Steel. Tube Pressure: 5.3 bar (76.1 psi). Tube Temperature: 160 °C (320 °F). Tube Material: Graphite. Vacuum: Yes. Shell Diameter: 285 mm (11.2 in). Length: 2,310 mm (90.9 in). Tube Number: 24. Tube Diameter: 32 mm (1.26 in). Tube Length: 1,790 mm (70.5 in). Tube Thickness: 12 mm (0.47 in). Nozzle Schedule: - Openings: 1-head with 2-50mm, 1-head with 1-100mm, shell: 2-100mm, 1-25mm.
