Hastelloy - C276 Vulcan Manufacturing Company Shell and Tube Heat Exchanger - IPP# 213333

Type: Heat Exchanger

Subtype: Shell and Tube

Manufacturer: Manning & Lewis

Condition: Used

Material: Hastelloy - C276

Heat Transfer Surface Area: 32.5 m² (350 ft²)

Orientation: Horizontal

• Duty: 2,900,000 BTU/hr
• Tema Registration Number: 11-00-99763 2 pass design

Shell Pressure: 48.3 bar (700 psi). Shell Temperature: 315.6 °C (600 °F). Shell Material: Stainless Steel 316. Tube Pressure: 48.3 bar (700 psi). Tube Temperature: 315.6 °C (600 °F). Tube Material: Hastelloy - C276. Tubesheet Material: Stainless Steel 316L. Vacuum: Yes. Head Material: Stainless Steel 316L. Length: 4,150 mm (163 in). Tube Type: Straight Tube. Tube Number: 155. Tube Diameter: 19.1 mm (0.75 in). Tube Length: 3,350 mm (132 in). Tube Thickness: 2 mm (0.08 in). Nozzle Schedule: - Shell Side Inlet: 4' - Shell Side Outlet: 8' - Tube Side Inlet: 8' - Tube Side Outlet: 8'.

Type: Heat Exchanger

Subtype: Shell and Tube

Manufacturer: Rubicon

Model: WC16BUG-144H

Condition: Used

Material: Hastelloy - C276

Heat Transfer Surface Area: 19.2 m² (207 ft²)

Orientation: Horizontal

0.750" diameter x 16 ga wall thickness 2 pass

Shell Pressure: 10.3 bar (150 psi). Shell Temperature: 204.4 °C (400 °F). Shell Material: Carbon Steel. Tube Pressure: 10.3 bar (150 psi). Tube Temperature: 204.4 °C (400 °F). Tube Material: Hastelloy - C276. Tubesheet Material: Hastelloy - Other. Head Material: Carbon Steel. Length: 4,150 mm (163 in). Tube Type: U-Tube. Tube Number: 88. Tube Diameter: 19.1 mm (0.75 in). Tube Thickness: 1.63 mm (0.06 in). Nozzle Schedule: - Tube side nozzles: two 6" - Shell side nozzles: two 8".

Type: Heat Exchanger

Subtype: Shell and Tube

Manufacturer: Tranter-Superchanger

Condition: Used

Material: Hastelloy - C276

Heat Transfer Surface Area: 2 m² (22 ft²)

Orientation: Vertical

• Internal plate coil baffle heaters (double)

Shell Material: Hastelloy - C276. Tube Pressure: 17.2 bar (250 psi). Tube Material: Hastelloy - C276. Tubesheet Material: Hastelloy - C276. Shell Diameter: 482.6 mm (19 in). Head Material: Hastelloy - C276. Length: 2,500 mm (98 in). Tube-side Passes: 14. Tube Type: Straight Tube.

Type: Heat Exchanger

Subtype: Shell and Tube

Manufacturer: Tranter-Superchanger

Condition: Used

Material: Hastelloy - C276

Heat Transfer Surface Area: 2 m² (22 ft²)

Orientation: Vertical

Internal plate coil baffle heaters(double)

Shell Material: Hastelloy - C276. Tube Pressure: 17.2 bar (250 psi). Tube Material: Hastelloy - C276. Tubesheet Material: Hastelloy - C276. Shell Diameter: 482.6 mm (19 in). Head Material: Hastelloy - C276. Length: 2,500 mm (98 in). Tube-side Passes: 14. Tube Type: Straight Tube.
