Stainless Steel 316 R. Lord & Sons Ltd Shell and Tube Heat Exchanger - IPP# 215339

Type: Heat Exchanger

Subtype: Shell and Tube

Manufacturer: R. Lord & Sons Ltd

Condition: Used

Material: Stainless Steel 316

Clad: Yes

Heat Transfer Surface Area: 13.8 m² (149 ft²)

Orientation: Horizontal

4-pass
fully insulated and clad

Shell Pressure: 5.17 bar (75 psi). Shell Temperature: 177 °C (351 °F). Shell Material: Carbon Steel. Tube Pressure: 8 bar (116 psi). Tube Temperature: 121 °C (250 °F). Tube Material: Stainless Steel 316. Tubesheet Material: Stainless Steel 316. Shell Diameter: 272 mm (10.7 in). Head Material: Stainless Steel 316. Length: 4,428 mm (174 in). Tube Type: U-Tube. Tube Number: 56. Tube Diameter: 19 mm (0.748 in). Tube Length: 3,956 mm (156 in). Nozzle Schedule: 2-50mm openings, shell with 2-50mm openings.

Type: Heat Exchanger

Subtype: Shell and Tube

Manufacturer: R. Lord & Sons Ltd

Condition: Used

Material: Stainless Steel 316

Heat Transfer Surface Area: 60 m² (646 ft²)

Orientation: Horizontal

12-internal 316 stainless steel baffle plates
2-316 stainless steel channel heads

Shell Pressure: 5.17 bar (75 psi). Shell Temperature: 250 °C (482 °F). Shell Material: Stainless Steel 316. Tube Pressure: 5.17 bar (75 psi). Tube Temperature: 150 °C (302 °F). Tube Material: Stainless Steel 316. Shell Diameter: 482 mm (19 in). Head Material: Stainless Steel 316. Length: 3,962 mm (156 in). Tube-side Passes: 2. Tube Number: 326. Tube Diameter: 19 mm (0.748 in). Tube Length: 3,081 mm (121 in). Nozzle Schedule: - Tube side openings: 1-head with 2-150mm, 1-head with no openings - Shell side openings: 2-150mm.

Type: Heat Exchanger

Subtype: Shell and Tube

Manufacturer: R. Lord & Sons Ltd

Condition: Used

Material: Stainless Steel 316

Clad: Yes

Heat Transfer Surface Area: 28 m² (301 ft²)

Orientation: Horizontal

(58) 316 stainless steel internal baffles
fully insulated and clad
(1) carbon steel channel head

Shell Pressure: 6.89 bar (100 psi). Shell Temperature: 260 °C (500 °F). Shell Material: Stainless Steel 316. Tube Pressure: 103 bar (1,500 psi). Tube Temperature: 350 °C (662 °F). Tube Material: Stainless Steel 316. Shell Diameter: 381 mm (15 in). Head Material: Carbon Steel. Length: 3,835 mm (151 in). Tube Type: U-Tube. Tube Number: 158. Tube Diameter: 17 mm (0.669 in). Tube Length: 3,657 mm (144 in). Nozzle Schedule: - Openings: tubeside - 1-75mm, 1-50mm; shell - 3-50mm.

Type: Heat Exchanger

Subtype: Shell and Tube

Manufacturer: R. Lord & Sons Ltd

Condition: Used

Material: Stainless Steel 316L

Heat Transfer Surface Area: 8.4 m² (90.4 ft²)

Orientation: Vertical

Shell Temperature: 200 °C (392 °F). Shell Material: Stainless Steel 316. Tube Pressure: 6.89 bar (100 psi). Tube Temperature: 200 °C (392 °F). Tube Material: Stainless Steel 316. Vacuum: Yes. Shell Diameter: 564 mm (22.2 in). Head Material: Carbon Steel. Length: 4,695 mm (185 in). Tube Type: U-Tube. Tube Number: 36. Tube Diameter: 30 mm (1.18 in). Tube Length: 3,959 mm (156 in). Tube Thickness: 2.11 mm (0.0831 in). Nozzle Schedule: 2-75mm, shell: 2-500mm, 1-300mm, 1-50mm.
