Type: Heat Exchanger
Subtype: Shell and Tube
Manufacturer: Graham Hart (Process Technology) Ltd
Condition: Used
Material: Stainless Steel 316L
Heat Transfer Surface Area: 83.6 m² (899.9 ft²)
Orientation: Horizontal
1-316L stainless steel bonnet head CE certified design code ASME V111 DIV 1 1998 (ADD' 2000) N.C.S
Shell Pressure: 5.5 bar (79.8 psi). Shell Temperature: 150 °C (302 °F). Shell Material: Stainless Steel 316. Tube Pressure: 9 bar (130.5 psi). Tube Temperature: 100 °C (212 °F). Tube Material: Stainless Steel 316. Tubesheet Material: Stainless Steel 316. Vacuum: Yes. Shell Diameter: 610 mm (24 in). Head Material: Stainless Steel 316. Length: 5,667 mm (223.1 in). Tube-side Passes: 8. Tube Type: U-Tube. Tube Number: 298. Tube Diameter: 19.1 mm (0.75 in). Tube Length: 4,700 mm (185 in). Tube Thickness: 1.65 mm (0.06 in). Nozzle Schedule: - Openings: - Tubeside: 2-150mm - Shell side: 2-200mm, 1-75mm, 3-50mm, 1-12mm.
Type: Heat Exchanger
Subtype: Shell and Tube
Manufacturer: Graham Hart (Process Technology) Ltd
Condition: Used
Material: Stainless Steel 304
Heat Transfer Surface Area: 9.6 m² (103.3 ft²)
Orientation: Horizontal
('U' bend not included)
Shell Pressure: 7 bar (101.5 psi). Shell Temperature: 330 °C (626 °F). Shell Material: Carbon Steel. Tube Pressure: 7 bar (101.5 psi). Tube Temperature: 330 °C (626 °F). Tube Material: Stainless Steel 304. Tubesheet Material: Stainless Steel 304L. Shell Diameter: 450 mm (17.7 in). Head Material: Carbon Steel. Tube Type: U-Tube. Tube Number: 84. Tube Diameter: 19 mm (0.75 in). Tube Length: 1,830 mm (72 in). Nozzle Schedule: openings: 2-75mm - Shell side openings: 3-50mm, 1-25mm.
Type: Heat Exchanger
Subtype: Shell and Tube
Manufacturer: R.Lords & Sons LTD.
Condition: Used
Material: Stainless Steel 316L
Heat Transfer Surface Area: 8.4 m² (90.4 ft²)
Orientation: Vertical
Shell Temperature: 200 °C (392 °F). Shell Material: Stainless Steel 316. Tube Pressure: 6.9 bar (100 psi). Tube Temperature: 200 °C (392 °F). Tube Material: Stainless Steel 316. Vacuum: Yes. Shell Diameter: 564 mm (22.2 in). Head Material: Carbon Steel. Length: 4,695 mm (184.8 in). Tube Type: U-Tube. Tube Number: 36. Tube Diameter: 30 mm (1.18 in). Tube Length: 3,959 mm (155.9 in). Tube Thickness: 2.1 mm (0.08 in). Nozzle Schedule: 2-75mm, shell: 2-500mm, 1-300mm, 1-50mm.
Type: Heat Exchanger
Subtype: Shell and Tube
Condition: Used
Material: Stainless Steel 316L
Heat Transfer Surface Area: 54.4 m² (585.8 ft²)
Orientation: Horizontal
316L stainless steel 'U' tubes multi-pass
Shell Pressure: 3.5 bar (50.8 psi). Shell Material: Stainless Steel Austenitic. Tube Pressure: 3.5 bar (50.8 psi). Tube Material: Stainless Steel Austenitic. Tubesheet Material: Stainless Steel Austenitic. Vacuum: Yes. Shell Diameter: 1,100 mm (43.3 in). Head Material: Carbon Steel. Length: 3,500 mm (137.8 in). Tube Type: U-Tube. Tube Number: 180. Tube Diameter: 28 mm (1.1 in). Tube Length: 3,500 mm (137.8 in). Nozzle Schedule: - Openings: tubeside - 2-80mm, 4-15mm (sockets), shell - 1-800mm, 1-600mm, 1-80mm (with sump).
