IPP# 241051, 37.2 m² (400 ft²) Stainless Steel 316 Shell and Tube Heat Exchanger For Sale
Add To Quote
Condition:
Used
Material:
Stainless Steel 316
Manufacturer:
Atlas Industrial
Heat Transfer Surface Area:
37.2 m² (400 ft²)
Orientation:
Vertical
Shell Pressure:
10.3 bar (150 psi)
Shell Temperature:
204.4 °C (400 °F)
Shell Material:
Carbon Steel
Tube Pressure:
10.3 bar (150 psi)
Tube Temperature:
204.4 °C (400 °F)
Tube Material:
Stainless Steel 316L
Tubesheet Material:
Stainless Steel 316L
Vacuum:
Yes
Shell Diameter:
457.2 mm (18 in)
Head Material:
Stainless Steel 316L
Length:
3,353 mm (132 in)
Shell-side Passes:
1
Tube-side Passes:
1
Tube Type:
Straight Tube
Tube Number:
262
Tube Diameter:
19.1 mm (0.75 in)
Tube Length:
2,388 mm (94 in)
Tube Thickness:
1.24 mm (0.05 in)
Nozzle Schedule:
One 12", Three 3", Two 2", and Two 1"
