Glasslined Pfaudler BE Batch-Type Agitated Reactor

  • Glasslined Pfaudler BE Batch-Type Agitated Reactor Glasslined Pfaudler BE Batch-Type Agitated Reactor
  • Glasslined Pfaudler BE Batch-Type Agitated Reactor Glasslined Pfaudler BE Batch-Type Agitated Reactor
  • Glasslined Pfaudler BE Batch-Type Agitated Reactor Glasslined Pfaudler BE Batch-Type Agitated Reactor
  • Glasslined Pfaudler BE Batch-Type Agitated Reactor Glasslined Pfaudler BE Batch-Type Agitated Reactor
  • Glasslined Pfaudler BE Batch-Type Agitated Reactor Glasslined Pfaudler BE Batch-Type Agitated Reactor
  • Glasslined Pfaudler BE Batch-Type Agitated Reactor Glasslined Pfaudler BE Batch-Type Agitated Reactor
  • Glasslined Pfaudler BE Batch-Type Agitated Reactor
  • Glasslined Pfaudler BE Batch-Type Agitated Reactor
  • Glasslined Pfaudler BE Batch-Type Agitated Reactor
  • Glasslined Pfaudler BE Batch-Type Agitated Reactor
  • Glasslined Pfaudler BE Batch-Type Agitated Reactor
  • Glasslined Pfaudler BE Batch-Type Agitated Reactor
Overview
Reactor
Batch-Type Agitated
Pfaudler
BE 16000
Used
Glasslined
18,200 L (4,800 gallons)
Glass Lined
Pressure Vessel
6 bar (87 psi)
Yes
200 °C (392 °F)
Jacket/Internal Coil
16 bar (232.1 psi)
200 °C (392 °F)
Half Pipe/Limpet
Carbon Steel
Dimensions
Vertical
2,600 mm (102.4 in)
2,750 mm (107.7 in)
Agitation System
Yes
Mechanical with Gas
driven by approx 35kw, 3/50/400 volt, 1450 rpm EEx de II CT4 motor via a reduction gearbox, 2-sets of 4-blade Cryolock agitator on shaft, gas type mechanical seal
35 kW (46.9 HP)
Beavertail
beavertail baffle
Heads
Dish
Glasslined
Dish
Glasslined
Other Specifications
Yes
Ring
Inlets & Outlets
openings top: 1-600mm manway with 2-100mm sightglasses, 4-300mm (1 with baffle), 5-200mm, 1-15mm (jacket), bottom: 1-150mm, 4-50mm (jacket)
Additional Information
  • working volume 16000 liter
  • glass type WWG9115,
  • design pressure internal -1/6 bar @ -25/200 degrees C (18200 liter),jacket -1/16 bar @ -25/200 degrees C (2 x 345 liter),
  • EEx de II CT4 motor
  • CE 0036 certified
  • jacket on straight side and bottom dish
  • design code: PED 97/23/EG, CAT IV, module G, fluid group 1, AD 2000,

Similar Equipment

Glasslined Pfaudler BE Batch-Type Agitated Reactor

Type: Reactor

Subtype: Batch-Type Agitated

Manufacturer: Pfaudler

Model: BE 16000

Condition: Used

Material: Glasslined

Capacity (Design): 16,000 L (4,250 gallons)

Internal Pressure: 6 bar (87 psi)

  • design pressure internal -1/6 bar @ -29/200 degrees C,
  • jacket -1/10 bar @ -29/200 degrees C,
  • CE0038,
  • glass type 9129,
  • driven by 45-52kW, 3/50-60/690-400/660-380/415-440 volt, 1477/1473/1479/1773 rpm EExd IIB II 2G T4 ATEX motor via a reduction gearbox,
  • 90 rpm shaft speed,
  • white glass body, blue glass shaft and baffle
  • design code: ASME VIII DIV 1, 2004 ANNEXE Z and essential safety requirements of PED/97/23/EC,

Internal Full Vacuum: Yes. Internal Temperature: 200 °C (392 °F). Jacket Pressure: 10 bar (145 psi). Jacket Temperature: 200 °C (392 °F). Jacket Material of Construction: Carbon Steel. Orientation: Vertical. Agitation: Yes. Diameter: 2,750 mm (108 in). Straight Side Length: 2,300 mm (89.6 in). Support Type: Lugs.

Glasslined Pfaudler BE Batch-Type Agitated Reactor

Type: Reactor

Subtype: Batch-Type Agitated

Manufacturer: Pfaudler

Model: BE 16000

Condition: Used

Material: Glasslined

Capacity (Design): 18,200 L (4,800 gallons)

Internal Pressure: 6 bar (87 psi)

  • working volume 16000 liter
  • design pressure internal -1/6 bar @ -25/200 degrees C (18200 liter), jacket -1/16 bar @ -25/200 degrees C (2 x 345 liter)
  • glass type WWG-9115
  • EEx de II CT4 motor
  • jacket on straight side and bottom dish
  • design code: PED 97/23/EG, CAT IV, module G, fluid group 1, AD 2000,
  • CE 0036 certified

Internal Temperature: 200 °C (392 °F). Jacket Pressure: 16 bar (232.1 psi). Jacket Temperature: 200 °C (392 °F). Jacket Material of Construction: Carbon Steel. Orientation: Vertical. Agitation: Yes. Diameter: 2,600 mm (102.4 in). Straight Side Length: 2,750 mm (107.7 in). Support Type: Ring.

Glasslined Pfaudler BE Batch-Type Agitated Reactor

Type: Reactor

Subtype: Batch-Type Agitated

Manufacturer: Pfaudler

Model: BE 16000

Condition: Used

Material: Glasslined

Capacity (Design): 18,200 L (4,800 gallons)

Internal Pressure: 6 bar (87 psi)

  • working volume 16000 liter
  • CE 0036
  • design pressure internal -1/6 bar @ -25/200 degrees C, jacket -1/16 bar @ -25/200 degrees C (2 x 345 liter)
  • glass type WWG-9115
  • driven by approx 45kw 3/50/400 volt 1450 rpm EEx de II CT4 motor,
  • design code: PED 97/23/EG, CAT IV, module G, fluid group 1, AD 2000

Internal Full Vacuum: Yes. Internal Temperature: 200 °C (392 °F). Jacket Pressure: 16 bar (232.1 psi). Jacket Temperature: 200 °C (392 °F). Jacket Material of Construction: Carbon Steel. Orientation: Vertical. Agitation: Yes. Diameter: 2,600 mm (102.4 in). Straight Side Length: 2,750 mm (107.7 in).

Glasslined Pfaudler BE Batch-Type Agitated Reactor

Type: Reactor

Subtype: Batch-Type Agitated

Manufacturer: Pfaudler

Model: BE 16000

Condition: Used

Material: Glasslined

Capacity (Design): 18,200 L (4,800 gallons)

Internal Pressure: 6 bar (87 psi)

  • working volume 16000 liter
  • CE 0036 certified
  • design pressure internal -1/6 bar @ -25/200 degrees C, jacket -1/16 bar @ -25/200 degrees C (2 x 345 liter)
  • driven by approx 35kw 3/50/400 volt 1450 rpm EEx de II CT4 motor
  • half pipe coil jacket on straight side and bottom dish
  • design code: PED 97/23/EG, CAT IV, module G, fluid group 1, AD 2000

Internal Full Vacuum: Yes. Internal Temperature: 200 °C (392 °F). Jacket Pressure: 16 bar (232.1 psi). Jacket Temperature: 200 °C (392 °F). Jacket Material of Construction: Carbon Steel. Orientation: Vertical. Agitation: Yes. Diameter: 2,600 mm (102.4 in). Straight Side Length: 2,750 mm (107.7 in). Support Type: Ring.
