Type: Heat Exchanger
Subtype: Shell and Tube
Manufacturer: Mersen
Model: BEM 20-1-30
Condition: Used
Material: Hastelloy - C276
Heat Transfer Surface Area: 15.1 m² (163 ft²)
Orientation: Vertical
304L SS with Hastelloy C clad tube sheet Hastelloy lined CS shell
Shell Pressure: 6.9 bar (100 psi). Shell Temperature: 182.2 °C (360 °F). Shell Material: Carbon Steel. Tube Pressure: 6.9 bar (100 psi). Tube Temperature: 182.2 °C (360 °F). Tube Material: Hastelloy - C276. Tubesheet Material: Stainless Steel 304. Vacuum: Yes. Shell Diameter: 610 mm (24 in). Head Material: Hastelloy - C276. Length: 1,500 mm (60 in). Tube Type: Straight Tube. Tube Number: 333. Tube Diameter: 19.1 mm (0.75 in). Tube Length: 660 mm (26 in). Tube Thickness: 0.76 mm (0.03 in). Nozzle Schedule: One 8" nozzle, One 4" nozzle, three 3" nozzles. .
Type: Heat Exchanger
Subtype: Shell and Tube
Manufacturer: Cosmos Metalurgical (Camarillo CA)
Model: BEM 12-1-72
Condition: Used
Material: Tantalum
Heat Transfer Surface Area: 9.3 m² (100 ft²)
Orientation: Horizontal
Rated 150/FV @ -20 to 400 degrees F tube side 150/FV @ -20 to 400 degrees F Shell Side Unit has (2) bolted flat heads (1) Tanalum, (1) CS with tantalum lining
Shell Pressure: 10.3 bar (150 psi). Shell Temperature: 204.4 °C (400 °F). Shell Material: Carbon Steel. Tube Pressure: 10.3 bar (150 psi). Tube Temperature: 204.4 °C (400 °F). Tube Material: Tantalum. Tubesheet Material: Tantalum. Vacuum: Yes. Shell Diameter: 304.8 mm (12 in). Head Material: Tantalum. Length: 2,400 mm (94.5 in). Tube Number: 84. Tube Diameter: 19.1 mm (0.75 in). Tube Length: 1,850 mm (72 in). Nozzle Schedule: - Nozzles: Shell side has two 4" nozzles with 1" reducing flanges - Inlet/outlet: Tube side inlet is 4", tube side outlet is 3" with a 1" drain..
Type: Heat Exchanger
Subtype: Shell and Tube
Manufacturer: Comtec
Condition: Used
Material: Tantalum
Heat Transfer Surface Area: 25.7 m² (276.6 ft²)
Orientation: Horizontal
Tantalum lined carbon steel tube sheets TUV APPROVED Pressure tube side -1/4 bar @ 170 degrees C (volume 122 liter), pressure shell side 4 bar @ -17/40 degrees C (volume 225 liter) Expansion joint manufactured by DeDietrich, serial number 27031, internal pressure rated -1/4 bar @ 170 degrees C (volume 67 liter), openings (1) DN80 and (1) DN150, second head: manufactured by DeDietrich, serial number 27030, internal pressure rated -1/4 bar @ 170 degrees C (volume 82 liter), openings (1) DN80 and (1) DN250
Shell Pressure: 4 bar (58 psi). Shell Temperature: 40 °C (104 °F). Shell Material: Carbon Steel. Tube Pressure: 4 bar (58 psi). Tube Temperature: 170 °C (338 °F). Tube Material: Tantalum. Tubesheet Material: Carbon Steel. Vacuum: Yes. Head Material: Glasslined. Length: 3,700 mm (145.8 in). Tube Type: Straight Tube. Tube Number: 179. Tube Diameter: 19.5 mm (0.77 in). Tube Length: 2,600 mm (102.4 in). Nozzle Schedule: - Openings: (1) DN40, (2) DN100, (1) DN150.
Type: Heat Exchanger
Subtype: Shell and Tube
Manufacturer: Comtec
Condition: Used
Material: Tantalum
Heat Transfer Surface Area: 5.1 m² (54.9 ft²)
Orientation: Horizontal
pressure tube side: -1/4 bar @ 170 degrees C (volume 23 liter), pressure shell side: 4 bar @ -17/40 degrees C (volume 82 liter) outside diameter:19,5mm x 3404mm length, wall thickness: 0,04mm with (2) glass lined steel heads, first head: manufactured by DeDietrich, serial number 27028, pressure -1/4 bar @ 170 degrees C (volume 9 liter), second head: manufactured by DeDietrich, serial number 27029, pressure -1/4 bar @ 170 degrees C (volume 9 liter)
Shell Pressure: 4 bar (58 psi). Shell Temperature: 40 °C (104 °F). Shell Material: Carbon Steel. Tube Pressure: 4 bar (58 psi). Tube Temperature: 170 °C (338 °F). Tube Material: Tantalum. Vacuum: Yes. Head Material: Glasslined. Tube Diameter: 19.5 mm (0.77 in). Tube Length: 3,400 mm (134 in). Tube Thickness: 0.04 mm (0.002 in). Nozzle Schedule: - Openings: - (4) DN80/PN10 - (2) DN200/PN10 - (2) DN100/PN16 - (1) DN40/PN16 - (1) DN150/PN16.
