design pressure tube side 10 barg + full vacuum @ -28/185 degrees C, shell 10 barg + full vacuum @ -28/185 degrees C, 4.3kW rated heat load, 1-channel head with removable flat plate, 1- coned head,
design code PD 5500 (2003) CAT 11 PER (1999) MODULE G CAT IV
Type: Heat Exchanger
Subtype: Shell and Tube
Manufacturer: Graham Hart (Process Technology) Ltd
Condition: Used
Material: Stainless Steel 316L
Heat Transfer Surface Area: 37 m² (398.3 ft²)
Orientation: Horizontal
Shell Pressure: 10.5 bar (152.3 psi). Shell Temperature: 180 °C (356 °F). Shell Material: Stainless Steel 316. Tube Pressure: 8 bar (116 psi). Tube Temperature: 180 °C (356 °F). Tube Material: Stainless Steel 316. Tubesheet Material: Stainless Steel 316. Shell Diameter: 406 mm (16 in). Head Material: Stainless Steel 316. Length: 3,900 mm (153.5 in). Shell-side Passes: 1. Tube-side Passes: 2. Tube Type: U-Tube. Tube Number: 80. Tube Diameter: 19.1 mm (0.75 in). Tube Length: 3,600 mm (141.7 in). Nozzle Schedule: tube side - 2-100mm, shell - 2-75mm, 1-50mm.
Type: Heat Exchanger
Subtype: Shell and Tube
Manufacturer: Graham Hart (Process Technology) Ltd
Condition: Used
Material: Stainless Steel 304
Heat Transfer Surface Area: 9.6 m² (103.3 ft²)
Orientation: Horizontal
('U' bend not included)
Shell Pressure: 7 bar (101.5 psi). Shell Temperature: 330 °C (626 °F). Shell Material: Carbon Steel. Tube Pressure: 7 bar (101.5 psi). Tube Temperature: 330 °C (626 °F). Tube Material: Stainless Steel 304. Tubesheet Material: Stainless Steel 304L. Shell Diameter: 450 mm (17.7 in). Head Material: Carbon Steel. Tube Type: U-Tube. Tube Number: 84. Tube Diameter: 19 mm (0.75 in). Tube Length: 1,850 mm (72 in). Nozzle Schedule: openings: 2-75mm - Shell side openings: 3-50mm, 1-25mm.
Type: Heat Exchanger
Subtype: Shell and Tube
Manufacturer: SRI
Model: AEM
Condition: Used
Material: Stainless Steel 316
Heat Transfer Surface Area: 25.2 m² (271.3 ft²)
Orientation: Horizontal
(1) c/steel channel head
Shell Pressure: 8.7 bar (126.2 psi). Shell Temperature: 210 °C (410 °F). Shell Material: Stainless Steel Other. Tube Pressure: 12.8 bar (185.6 psi). Tube Temperature: 210 °C (410 °F). Tube Material: Stainless Steel 316. Vacuum: Yes. Shell Diameter: 660 mm (26 in). Head Material: Carbon Steel. Length: 3,100 mm (123 in). Shell-side Passes: 1. Tube-side Passes: 6. Tube Type: U-Tube. Tube Number: 80. Tube Diameter: 19.3 mm (0.76 in). Tube Length: 2,600 mm (102.4 in). Nozzle Schedule: - Head openings: tubeside - 2-2", shell side - 1-6", 1-3", 2-2", 1-1 1/2".
Type: Heat Exchanger
Subtype: Shell and Tube
Manufacturer: Johnson Hunt LTD
Model: AEM
Condition: Unused
Material: Carbon Steel
Heat Transfer Surface Area: 5.2 m² (56 ft²)
Orientation: Horizontal
3/4' diameter x 14 gauge x 8' long tubes 2 heads
Shell Pressure: 33 bar (479 psi). Shell Temperature: 260 °C (500 °F). Shell Material: Carbon Steel. Tube Pressure: 33 bar (479 psi). Tube Temperature: 260 °C (500 °F). Tube Material: Carbon Steel. Tubesheet Material: Carbon Steel. Vacuum: Yes. Shell Diameter: 203.2 mm (8 in). Head Material: Carbon Steel. Shell-side Passes: 1. Tube-side Passes: 1. Tube Number: 37. Tube Diameter: 19.1 mm (0.75 in). Tube Length: 2,450 mm (96 in). Tube Thickness: 2 mm (0.08 in).
