Type: Heat Exchanger
Subtype: Shell and Tube
Manufacturer: Southern Heat Exchanger
Condition: Used
Material: Stainless Steel 304
Heat Transfer Surface Area: 135.8 m² (1,450 ft²)
Orientation: Horizontal
TEMA Type 23-238 AES Order number 80-100, 1" pitch. 304SS tube sheet 28 1/8" diameter x 1 1/8" thick. Exchanger has (1) channel head, (1) head floating head with external cover. 23' over all length.
Shell Pressure: 9.7 bar (140 psi). Shell Temperature: 62.8 °C (145 °F). Shell Material: Stainless Steel 304. Tube Pressure: 6.9 bar (100 psi). Tube Temperature: 93.3 °C (200 °F). Tube Material: Stainless Steel 304. Tubesheet Material: Stainless Steel 304. Shell Diameter: 610 mm (24 in). Head Material: Carbon Steel. Length: 5,850 mm (231 in). Tube-side Passes: 4. Tube Type: Straight Tube. Tube Number: 376. Tube Diameter: 19.1 mm (0.75 in). Tube Length: 6,050 mm (237.6 in). Tube Thickness: 1.65 mm (0.07 in). Nozzle Schedule: Openings include: Channel Head, (2) 6"; Shell (2) 6"..
Type: Heat Exchanger
Subtype: Shell and Tube
Manufacturer: Southern Heat Exchanger
Condition: Used
Material: Hastelloy - C276
Heat Transfer Surface Area: 8.1 m² (87 ft²)
Orientation: Horizontal
Shell Pressure: 13.8 bar (200 psi). Shell Temperature: 204.4 °C (400 °F). Shell Material: Carbon Steel. Tube Pressure: 3.4 bar (50 psi). Tube Temperature: 204.4 °C (400 °F). Tube Material: Hastelloy - C276. Tubesheet Material: Hastelloy - C276. Vacuum: Yes. Shell Diameter: 152.4 mm (6 in). Head Material: Hastelloy - C276. Tube Type: Straight Tube. Tube Number: 28. Tube Diameter: 19.1 mm (0.75 in). Tube Length: 4,800 mm (189 in). Tube Thickness: 1.02 mm (0.04 in). Nozzle Schedule: - Openings: Shell (1) 6", (1) 2", (1) 1"; One Head - (1) 3", (1) 1"; Other Head (1) 3" .
Type: Heat Exchanger
Subtype: Shell and Tube
Manufacturer: Southern Heat Exchanger
Condition: Used
Material: Monel
Heat Transfer Surface Area: 107.6 m² (1,150 ft²)
Orientation: Horizontal
400 tube sheets previously used as a condenser. tube sheets are 32" diameter x 1.9375" thick With (2) CS flat channel heads
Shell Pressure: 10.3 bar (150 psi). Shell Temperature: 260 °C (500 °F). Shell Material: Carbon Steel. Tube Pressure: 10.3 bar (150 psi). Tube Temperature: 260 °C (500 °F). Tube Material: Monel. Tubesheet Material: Monel. Shell Diameter: 813 mm (32 in). Head Material: Carbon Steel. Length: 4,550 mm (180 in). Tube Number: 456. Tube Diameter: 25.4 mm (1 in). Tube Length: 3,650 mm (144 in). Tube Thickness: 2.8 mm (0.11 in). Nozzle Schedule: - Openings: shell side- 2-6", tube side- 1-16", 1-10".
Type: Heat Exchanger
Subtype: Shell and Tube
Manufacturer: Southern Heat Exchanger
Model: BEM
Condition: Used
Material: Carbon Steel
Heat Transfer Surface Area: 125.4 m² (1,350 ft²)
Orientation: Vertical
Size 35-96 shell w/48" diameter expansion joint 2 bonnet heads 13' overall shell w/48" diameter expansion joint.
Shell Pressure: 31 bar (450 psi). Shell Temperature: 260 °C (500 °F). Shell Material: Carbon Steel. Tube Pressure: 3.4 bar (50 psi). Tube Temperature: 260 °C (500 °F). Tube Material: Carbon Steel. Tubesheet Material: Carbon Steel. Vacuum: Yes. Shell Diameter: 914 mm (36 in). Head Material: Carbon Steel. Length: 3,950 mm (156 in). Tube Type: Straight Tube. Tube Number: 645. Tube Diameter: 25.4 mm (1 in). Tube Length: 2,450 mm (96 in). Tube Thickness: 2.8 mm (0.11 in). Nozzle Schedule: Openings: shell side (1) 2", (1) 3", tube side (1) 12", (1) 4". .
