• 6300 liter working volume
• CE6300 series,
• design pressure -1/3.5 bar @ -25/170 degrees C (7575 liter),
• glass type 3009U,
• design code: AD-M 2000, CAT IV, 97/23/EC,

• design pressure 1.030/3.5 bar @ -15/100 degrees C,
• design code ASME VIII DIV. 1. 1989 (DEC 90 ADDENDA)

With (2) PTFE lined centrifugal pumps, manufactured by Richter Chemie, type PCK/F 32-160, 2900 rpm, 165mm diameter impellor, mounted on a base plate,

• Rated for lethal service.
• Nozzles with Inconel 625 inlay.
• Glasslined beavertail baffle with WIKA TR-10 & PT100 temperature probes.
• Mechanically sealed agitator: FlowServe MD-200 DN140.
• See sales comments for additional options.

• Lined with 3008 glass.

• design pressure -1.030/3.5 bar @ -15/100 degrees C,
• design code ASME VIII DIV 1 1989 (DEC 90 ADDENDA),

With (2) gear pumps.

• design pressure -1.030/3.5 bar @ -15/100 degrees C,
• design code ASME VIII DIV 1 1989 (DEC 90 ADDENDA),

(2) 25m3/hr @ 11.8m head PTFE lined centrifugal pumps manufactured by CP Pumpen AG, type MKPL 80-50-200, 196mm diameter impellor, 1450 rpm, 20/30 degrees C, CE Ex II 2GD T1-T4 classification, mounted on a baseplate,

• working volume 170 liter
• design pressure -1/6 barg @ -20/165 degrees C (177 liter),
• each clamped flat end with Davit assist
• design code: ASME VIII DIV 1. 2004. annexe Z. and essential safety requirements of PED 97/23/EC. group 1. CAT IV module G

• working volume 170 liter
• design pressure -1/6 barg @ -20/165 degrees C (177 liter)
• glass type 9129 white glass
• clamped flat ends each with a davit assist
• design code: ASME VIII DIV 1. 2004. annexe Z. and essential safety requirements of PED 97/23/EC. group 1. CAT IV module G

• 1600 liter working volume
• design pressure internal 3.5 bar + full vacuum @ -25/170 degrees C,
• jacket 10 barg + full vacuum @ -29/185 degrees C
• off set Lightnin model LS-55 agitator drive, serial #Q58262-1
• Hastelloy C22 turbine blades on shaft.
• IP55 motor
• design code BS5500 CAT 2 Support: Lugs.

• 34,000 liter working capacity,

• design pressure -1.030/3,5 barg @ -15/100 degrees C,

• white glass type 9129,

• design code ASME VIII DIV 1 1989 (DEC 90 ADDENDA)

  With (2) PTFE lined centrifugal pumps.

• design pressure -1.03/3.5 bar @ -15/100 degrees C,
• glass type 9129,
• design code: ASME VIII DIV 1,

(2) PFA lined centrifugal pumps,

• 34,000 liter working capacity,
• design pressure -1.030/3.5 barg @ -15/100 degrees C,
• white glass type 9129,
• design code: ASME VIII DIV 1 1989 (DEC '90.ADDENDA)

(2) PTFE lined centrifugal pumps.

• design pressure 6 bar + full vacuum @ -20/165 degrees C,
• design code: PD5500 1991,

• 34000 liter working capacity,
• design pressure -1.030/3.5 bar @ -15/100 degrees C,
• design code: ASME VIII DIV 1, 1989 (DEC '90' ADDENDA)

(1) 10m3/hr @35m head PFA lined centrifugal pump, manufactured by Richter, type PCKXF32-160, serial #926676/2/1, 2900 rpm, 132mm diameter impellor, driven by 7.5kW, 3/50/415 volt, 2900 rpm EEx de IIB T4 motor, double mechanical seal, mounted on a baseplate

• 34000 liter working capacity,
• design pressure -1.03/3.5 bar @ -15/100 degrees C,
• design code: ASME VIII DIV 1 1989 (Dec '90.Addenda)

(1) PFA lined centrifugal pump, manufactured by Richter, type PCK/F 32-160, serial #916285/3/1, 2900 rpm, 145mm diameter impellor,

• Overall height 3.4 meters.

• With insulation & cladding on straight side and bottom dish.

• Approval NJ Spec #103-213-

• With insulation & cladding on straight side and bottom dish.

• Built to TUV design code.
• Shaft with Crane mechanical seal with lubricator.
• Vessel lined with blue 3009 glass.
• Agitator lined with white glass.

• Built to TUV design code.
• Lined with white 809 & Duravit 259 glass.
• Motor operating at 7.5 - 8.6 kW at 1450 - 1750 RPM.

20000 liter CE, TUV glass type 809 internal pressure -1/3 bar @ -20/150 degrees C (22500 liter) driven by 7.5/8.6 kw, 3/50/60/660-690/380-415/440-480 volt, 1450-1750 rpm CE, ATEX motor via a Flender 11.64:1 ratio reduction gearbox 4-blade pitched turbine paddle on shaft, Crane mechanical seal with lubricator, white glass body and agitator shaft

• Storage tank total volume 27,600 liter.
• 4050 mm from top nozzle to bottom nozzle.
