Carbon Steel Graham Hart Ltd CEU Shell and Tube Heat Exchanger - IPP# 242625

Type: Heat Exchanger

Subtype: Shell and Tube

Manufacturer: Graham Hart Ltd

Model: CEU

Condition: Used

Material: Carbon Steel

Heat Transfer Surface Area: 14 m² (150.6 ft²)

Orientation: Horizontal

• 250.11kW heat load,
• design pressure tubeside 10 barg + full vacuum @ 200 degrees C,
• shell side 11.5 barg + full vacuum @ 250 degrees C,
• (1) carbon steel bolted channel head with removable end plate,
• (10) carbon steel internal baffle plates,
• design code: PD5500 2000 CAT 2 + PED

Shell Pressure: 11.5 bar (166.8 psi). Shell Temperature: 250 °C (482 °F). Shell Material: Carbon Steel. Tube Pressure: 10 bar (145 psi). Tube Temperature: 200 °C (392 °F). Tube Material: Carbon Steel. Tubesheet Material: Carbon Steel. Vacuum: Yes. Shell Diameter: 305 mm (12 in). Head Material: Carbon Steel. Length: 4,000 mm (157.5 in). Tube-side Passes: 2. Tube Type: U-Tube. Tube Number: 42. Tube Diameter: 19.1 mm (0.75 in). Tube Length: 2,800 mm (109.6 in). Tube Thickness: 2.1 mm (0.08 in). Nozzle Schedule: openings tube side 2-80mm, shell side 1-50mm, 1-25mm.

Type: Heat Exchanger

Subtype: Shell and Tube

Manufacturer: Joseph Oat

Model: CEU

Condition: Unused

Material: Stainless Steel 304

Heat Transfer Surface Area: 367.6 m² (3,950 ft²)

Orientation: Vertical

TEMA type CEU, size 30-336. Shell 2-8" connections; tube 2-8" connections.

Shell Pressure: 17.2 bar (250 psi). Shell Temperature: 65.6 °C (150 °F). Shell Material: Carbon Steel. Tube Pressure: 10.3 bar (150 psi). Tube Temperature: 65.6 °C (150 °F). Tube Material: Stainless Steel 304. Tubesheet Material: Stainless Steel 304. Head Material: Carbon Steel. Shell-side Passes: 1. Tube-side Passes: 2. Tube Type: U-Tube. Tube Number: 350. Tube Diameter: 19.1 mm (0.75 in). Tube Length: 8,550 mm (336 in). Tube Thickness: 1.27 mm (0.05 in). Nozzle Schedule: Shell 2-8" connections; tube 2-8" connections..

Type: Heat Exchanger

Subtype: Shell and Tube

Manufacturer: Graham Hart Ltd

Model: BEM

Condition: Used

Material: Stainless Steel 316L

Heat Transfer Surface Area: 4.9 m² (52.2 ft²)

Orientation: Vertical

• rated load 28.14kW
• unit size OD 273
• design pressure tube side 10 barg + full vacuum @ -29/185 degrees C,
• shell side 10 barg + full vacuum @ -29/185 degrees C
• shell with expansion bellows
• 1-316L stainless steel bonnet head,
• 1-316L stainless steel coned reduction head,
• (12) 316L stainless steel internal baffle plates
• design code: PD5500 (2000) CAT II PER (1999) Module G CAT II, CE 0040

Shell Pressure: 10 bar (145 psi). Shell Temperature: 185 °C (365 °F). Shell Material: Stainless Steel 316L. Tube Pressure: 10 bar (145 psi). Tube Temperature: 185 °C (365 °F). Tube Material: Stainless Steel 316L. Tubesheet Material: Stainless Steel 316L. Vacuum: Yes. Shell Diameter: 273 mm (10.7 in). Head Material: Stainless Steel 316L. Length: 1,600 mm (63.2 in). Tube-side Passes: 1. Tube Type: Straight Tube. Tube Number: 81. Tube Diameter: 19.1 mm (0.75 in). Tube Length: 1,000 mm (39.4 in). Tube Thickness: 1.63 mm (0.06 in). Nozzle Schedule: openings tube side 1-head with 1-75mm, 1-head with 1-150mm, shell: 2-50mm,.

Type: Heat Exchanger

Subtype: Shell and Tube

Manufacturer: Graham Hart Ltd

Model: BEM

Condition: Used

Material: Stainless Steel 316L

Heat Transfer Surface Area: 14.6 m² (156.6 ft²)

Orientation: Horizontal

• size OD-324,
• rated heat load 38.47kw
• design pressure tube side 10 barg + full vacuum @ -29/185 degrees C,
• shell side 10 barg + full vacuum @ -29/185 degrees C,
• 2- 316L stainless steel flat bonnet heads,
• (19) internal 316L stainless steel baffle plates,
• CE0040
• design code PD 5500 (2000) CAT 2 PER (1999) MODULE G CAT II

Shell Pressure: 10 bar (145 psi). Shell Temperature: 185 °C (365 °F). Shell Material: Stainless Steel 316L. Tube Pressure: 10 bar (145 psi). Tube Temperature: 185 °C (365 °F). Tube Material: Stainless Steel 316L. Tubesheet Material: Stainless Steel 316L. Vacuum: Yes. Shell Diameter: 305 mm (12 in). Head Material: Stainless Steel 316L. Length: 2,900 mm (113.2 in). Tube-side Passes: 8. Tube Type: Straight Tube. Tube Number: 152. Tube Diameter: 12.7 mm (0.5 in). Tube Length: 2,400 mm (94.5 in). Tube Thickness: 1.65 mm (0.06 in). Nozzle Schedule: openings tube side 2-50mm, shell side 2-100mm.
