Unused Stainless Steel 304 Shell and Tube Heat Exchanger - IPP# 34268

Type: Heat Exchanger

Subtype: Shell and Tube

Manufacturer: Graham Hart Ltd

Model: CEU

Condition: Used

Material: Carbon Steel

Heat Transfer Surface Area: 14 m² (150.6 ft²)

Orientation: Horizontal

• 250.11kW heat load,
• design pressure tubeside 10 barg + full vacuum @ 200 degrees C,
• shell side 11.5 barg + full vacuum @ 250 degrees C,
• (1) carbon steel bolted channel head with removable end plate,
• (10) carbon steel internal baffle plates,
• design code: PD5500 2000 CAT 2 + PED

Shell Pressure: 11.5 bar (166.8 psi). Shell Temperature: 250 °C (482 °F). Shell Material: Carbon Steel. Tube Pressure: 10 bar (145 psi). Tube Temperature: 200 °C (392 °F). Tube Material: Carbon Steel. Tubesheet Material: Carbon Steel. Vacuum: Yes. Shell Diameter: 305 mm (12 in). Head Material: Carbon Steel. Length: 4,000 mm (157.5 in). Tube-side Passes: 2. Tube Type: U-Tube. Tube Number: 42. Tube Diameter: 19.1 mm (0.75 in). Tube Length: 2,800 mm (109.6 in). Tube Thickness: 2.1 mm (0.08 in). Nozzle Schedule: openings tube side 2-80mm, shell side 1-50mm, 1-25mm.

Type: Heat Exchanger

Subtype: Shell and Tube

Manufacturer: Graham Hart Ltd

Model: CEU

Condition: Used

Material: Carbon Steel

Heat Transfer Surface Area: 14 m² (150.6 ft²)

Orientation: Horizontal

• 250.11kW heat load,
• design pressure tubeside 10 barg + full vacuum @ 200 degrees C,
• shell side 11.5 barg + full vacuum @ 250 degrees C,
• (1) carbon steel bolted channel head with removable end plate,
• (10) carbon steel internal baffle plates,
• design code: PD5500 2000 CAT 2 + PED

Shell Pressure: 11.5 bar (166.8 psi). Shell Temperature: 250 °C (482 °F). Shell Material: Carbon Steel. Tube Pressure: 10 bar (145 psi). Tube Temperature: 200 °C (392 °F). Tube Material: Carbon Steel. Tubesheet Material: Carbon Steel. Vacuum: Yes. Shell Diameter: 305 mm (12 in). Head Material: Carbon Steel. Length: 4,000 mm (157.5 in). Tube-side Passes: 2. Tube Type: U-Tube. Tube Number: 42. Tube Diameter: 19.1 mm (0.75 in). Tube Length: 2,800 mm (109.6 in). Tube Thickness: 2.1 mm (0.08 in). Nozzle Schedule: openings tube side 2-80mm, shell side 1-50mm, 1-25mm.

Type: Heat Exchanger

Subtype: Shell and Tube

Manufacturer: Manning and Lewis

Condition: Used

Material: Stainless Steel 304

Heat Transfer Surface Area: 100.8 m² (1,100 ft²)

Orientation: Horizontal

Job #: 161730

Shell Temperature: 176.7 °C (350 °F). Shell Material: Carbon Steel. Tube Pressure: 10.3 bar (150 psi). Tube Temperature: 176.7 °C (350 °F). Tube Material: Stainless Steel 304. Tubesheet Material: Stainless Steel 304. Head Material: Stainless Steel 304. Length: 4,850 mm (191 in). Tube Type: Straight Tube. Tube Number: 402. Tube Diameter: 19.1 mm (0.75 in). Tube Thickness: 1.52 mm (0.06 in). Nozzle Schedule: - Shell side nozzles: two 4" with 1" vents and drains - Tube side nozzles: 2" and 1.5" with 1/2 " vent and drains.. Capacity: 568 L (150 gallons).
