Shell and Tube Heat Exchanger 15.6 m² (168 ft²) Stainless Steel 316 For Sale - IPP# 241174

Type: Heat Exchanger

Subtype: Shell and Tube

Manufacturer: Atlas Industrial

Model: TEMA BEM 17-96

Condition: Used

Material: Stainless Steel 316

Heat Transfer Surface Area: 37.2 m² (400 ft²)

Orientation: Vertical

Shell Pressure: 10.3 bar (150 psi). Shell Temperature: 204.4 °C (400 °F). Shell Material: Carbon Steel. Tube Pressure: 10.3 bar (150 psi). Tube Temperature: 204.4 °C (400 °F). Tube Material: Stainless Steel 316L. Tubesheet Material: Stainless Steel 316L. Vacuum: Yes. Shell Diameter: 457.2 mm (18 in). Head Material: Stainless Steel 316L. Length: 3,350 mm (132 in). Shell-side Passes: 1. Tube-side Passes: 1. Tube Type: Straight Tube. Tube Number: 262. Tube Diameter: 19.1 mm (0.75 in). Tube Length: 2,400 mm (94 in). Tube Thickness: 1.24 mm (0.05 in). Nozzle Schedule: One 12", Three 3", Two 2", and Two 1".

Type: Heat Exchanger

Subtype: Shell and Tube

Manufacturer: Atlas Industrial

Condition: Unused

Material: Carbon Steel

Heat Transfer Surface Area: 28.5 m² (307 ft²)

Orientation: Horizontal

Type BEM. Replacement shell, spare, no heads with the unit.

Shell Pressure: 10.3 bar (150 psi). Shell Temperature: 662 °C (1,200 °F). Shell Material: Carbon Steel. Tube Pressure: 10.3 bar (150 psi). Tube Temperature: 662 °C (1,200 °F). Tube Material: Carbon Steel. Tubesheet Material: Carbon Steel. Vacuum: Yes. Shell Diameter: 406.4 mm (16 in). Length: 3,600 mm (140.8 in). Tube Type: Straight Tube. Tube Number: 135. Tube Diameter: 19.1 mm (0.75 in). Tube Length: 3,600 mm (140.8 in). Tube Thickness: 0.08 mm (0.003 in).

Type: Heat Exchanger

Subtype: Shell and Tube

Manufacturer: Atlas Industrial

Condition: Used

Material: Carbon Steel

Heat Transfer Surface Area: 26.8 m² (289 ft²)

Orientation: Vertical

• TEMA size 24-72 Glycol Heater

Shell Pressure: 12.1 bar (175 psi). Shell Temperature: 190.6 °C (375 °F). Shell Material: Carbon Steel. Tube Pressure: 10.3 bar (150 psi). Tube Temperature: 190.6 °C (375 °F). Tube Material: Carbon Steel. Tubesheet Material: Carbon Steel. Vacuum: Yes. Shell Diameter: 610 mm (24 in). Head Material: Carbon Steel. Length: 2,150 mm (85 in). Shell-side Passes: 1. Tube-side Passes: 2. Tube Type: U-Tube. Tube Number: 211. Tube Diameter: 19.1 mm (0.75 in). Tube Length: 2,150 mm (84 in). Tube Thickness: 2.1 mm (0.08 in). Nozzle Schedule: Two 10", One 4", one 3" one 2", one 1.5", three 1", .

Type: Heat Exchanger

Subtype: Shell and Tube

Manufacturer: Atlas Industrial

Model: BEM 20-60

Condition: Used

Material: Hastelloy - Other

Clad: Yes

Heat Transfer Surface Area: 27.9 m² (300 ft²)

Orientation: Vertical

Shell Pressure: 10.3 bar (150 psi). Shell Temperature: 204.4 °C (400 °F). Shell Material: Carbon Steel. Tube Pressure: 10.3 bar (150 psi). Tube Temperature: 204.4 °C (400 °F). Tube Material: Hastelloy - Other. Tubesheet Material: Hastelloy - C276. Vacuum: Yes. Shell Diameter: 508 mm (20 in). Head Material: Hastelloy - Other. Length: 1,450 mm (57 in). Shell-side Passes: 1. Tube-side Passes: 1. Tube Type: Straight Tube. Tube Number: 324. Tube Diameter: 19.1 mm (0.75 in). Tube Length: 1,450 mm (57 in). Tube Thickness: 1.24 mm (0.05 in). Nozzle Schedule: One 10", Three 4", One 3", Two 1".
