IPP# 245619, 17.6 m² (189.4 ft²) Stainless Steel 316L Shell and Tube Heat Exchanger For Sale

IPP# 245619, 17.6 m² (189.4 ft²) Stainless Steel 316L Shell and Tube Heat Exchanger For Sale

Condition:

Used

Material:

Stainless Steel 316L

Manufacturer:

GEA

Heat Transfer Surface Area:

17.6 m² (189.4 ft²)

Orientation:

Horizontal

Shell Pressure:

1.38 bar (20 psi)

Shell Temperature:

40.2 °C (104.4 °F)

Shell Material:

Stainless Steel 316L

Tube Pressure:

10 bar (145 psi)

Tube Temperature:

9.7 °C (49.4 °F)

Tube Material:

Stainless Steel 316L

Tubesheet Material:

Stainless Steel 316L

Vacuum:

Yes

Shell Diameter:

323.9 mm (12.8 in)

Length:

2,986 mm (117.6 in)

Tube Type:

Straight Tube

Tube Number:

98

Tube Diameter:

19.1 mm (0.75 in)

Tube Length:

3,000 mm (118.1 in)

Tube Thickness:

1.65 mm (0.06 in)

Nozzle Schedule:

shell side: (1) DN50, (1) DN80, (1) DN100; tube side: (2) DN150

Capacity:

280 L (74 gallons)

Heat Exchanger Tube Capacity:

140 L (37 gallons)

Additional Info:
