Hastelloy - C276 Shell and Tube Heat Exchanger - IPP# 706922

Type: Heat Exchanger

Subtype: Shell and Tube

Manufacturer: Langfields Ltd

Condition: Used

Material: Stainless Steel 316

Heat Transfer Surface Area: 13.5 m² (145.3 ft²)

Orientation: Horizontal

multi-pass 2-carbon steel flat channel heads

Shell Pressure: 2 bar (29 psi). Shell Temperature: 170 °C (338 °F). Shell Material: Stainless Steel Other. Tube Pressure: 7 bar (101.5 psi). Tube Temperature: 100 °C (212 °F). Tube Material: Stainless Steel 316. Shell Diameter: 552 mm (21.7 in). Head Material: Carbon Steel. Length: 1,750 mm (69.8 in). Tube Number: 56. Tube Diameter: 50 mm (1.97 in). Tube Length: 1,750 mm (69.8 in). Nozzle Schedule: - Openings: - Tubeside: 2-50mm, 2-12mm sockets - Shell side: 1-150mm, 2-50mm.

Type: Heat Exchanger

Subtype: Shell and Tube

Manufacturer: Vulcan Manufacturing Company

Condition: Used

Material: Hastelloy - C276

Heat Transfer Surface Area: 74 m² (796 ft²)

Orientation: Horizontal

23" diameter x 1.25" thick. (2) bolted dished heads

Shell Pressure: 15.5 bar (225 psi). Shell Temperature: 260 °C (500 °F). Shell Material: Carbon Steel. Tube Pressure: 2.4 bar (35 psi). Tube Temperature: 260 °C (500 °F). Tube Material: Hastelloy - C276. Tubesheet Material: Hastelloy - C276. Shell Diameter: 584 mm (23 in). Head Material: Hastelloy - C276. Length: 4,650 mm (184 in). Tube-side Passes: 1. Tube Number: 155. Tube Diameter: 31.8 mm (1.25 in). Tube Length: 4,800 mm (188 in). Tube Thickness: 2 mm (0.08 in). Nozzle Schedule: Openings: Shell - (1) 4", (1) 2"; One Head (1) 8", (1) 2"; Other head - (1)16", (1) 1".

Type: Heat Exchanger

Subtype: Shell and Tube

Manufacturer: Manning & Lewis

Condition: Used

Material: Hastelloy - C276

Heat Transfer Surface Area: 32.5 m² (350 ft²)

Orientation: Horizontal

• Duty: 2,900,000 BTU/hr
• Tema Registration Number: 11-00-99763 2 pass design

Shell Pressure: 48.3 bar (700 psi). Shell Temperature: 315.6 °C (600 °F). Shell Material: Stainless Steel 316. Tube Pressure: 48.3 bar (700 psi). Tube Temperature: 315.6 °C (600 °F). Tube Material: Hastelloy - C276. Tubesheet Material: Stainless Steel 316L. Vacuum: Yes. Head Material: Stainless Steel 316L. Length: 4,150 mm (163 in). Tube Type: Straight Tube. Tube Number: 155. Tube Diameter: 19.1 mm (0.75 in). Tube Length: 3,350 mm (132 in). Tube Thickness: 2 mm (0.08 in). Nozzle Schedule: - Shell Side Inlet: 4' - Shell Side Outlet: 8' - Tube Side Inlet: 8' - Tube Side Outlet: 8'.
