Type: Heat Exchanger
Subtype: Shell and Tube
Manufacturer: Atlas Industrial
Condition: Used
Material: Hastelloy - C276
Heat Transfer Surface Area: 35 m² (377 ft²)
Orientation: Vertical
Shell Pressure: 10.3 bar (150 psi). Shell Temperature: 204.4 °C (400 °F). Shell Material: Carbon Steel. Tube Pressure: 10.3 bar (150 psi). Tube Temperature: 204.4 °C (400 °F). Tube Material: Hastelloy - C276. Tubesheet Material: Hastelloy - C276. Vacuum: Yes. Shell Diameter: 610 mm (24 in). Head Material: Hastelloy - C276. Length: 559 mm (22 in). Shell-side Passes: 4. Tube-side Passes: 4. Tube Type: Straight Tube. Tube Number: 481. Tube Diameter: 19.1 mm (0.75 in). Tube Length: 559 mm (22 in). Tube Thickness: 457.2 mm (18 in). Nozzle Schedule: (2) 4" inlet/outlet, (2) 1" vent/drain, (1) 1/2" drain, (1) 10" inlet. (1) 3" outlet. (1) 4" outlet.
Type: Heat Exchanger
Subtype: Shell and Tube
Manufacturer: Atlas Industrial
Model: BEM
Condition: Used
Material: Hastelloy - C276
Heat Transfer Surface Area: 28.5 m² (307 ft²)
Orientation: Vertical
Shell Pressure: 10.3 bar (150 psi). Shell Temperature: 204.4 °C (400 °F). Shell Material: Carbon Steel. Tube Pressure: 10.3 bar (150 psi). Tube Temperature: 204.4 °C (400 °F). Tube Material: Hastelloy - C276. Tubesheet Material: Hastelloy SB-575. Vacuum: Yes. Shell Diameter: 508 mm (20 in). Head Material: Hastelloy SB-575. Length: 1,450 mm (58 in). Shell-side Passes: 1. Tube-side Passes: 1. Tube Type: Straight Tube. Tube Number: 324. Tube Diameter: 19.1 mm (0.75 in). Tube Length: 1,450 mm (58 in). Tube Thickness: 457.2 mm (18 in). Nozzle Schedule: (1x) 10" inlet, (1x) 3" outlet, (1x) 4" outlet, (2x) 4" inlet/outlet (2x) 1" vent/drain.
Type: Heat Exchanger
Subtype: Shell and Tube
Manufacturer: Atlas Industrial
Model: 20-42 BEM
Condition: Used
Material: Hastelloy - C276
Heat Transfer Surface Area: 19.6 m² (211 ft²)
Orientation: Vertical
Shell Pressure: 10.3 bar (150 psi). Shell Temperature: 204.4 °C (400 °F). Shell Material: Carbon Steel. Tube Pressure: 10.3 bar (150 psi). Tube Temperature: 204.4 °C (400 °F). Tube Material: Hastelloy - C276. Tubesheet Material: Hastelloy - C276. Vacuum: Yes. Shell Diameter: 508 mm (20 in). Head Material: Hastelloy - C276. Length: 1,000 mm (40.3 in). Shell-side Passes: 1. Tube-side Passes: 1. Tube Type: Straight Tube. Tube Number: 324. Tube Diameter: 19.1 mm (0.75 in). Tube Length: 1,000 mm (40 in). Tube Thickness: 1.24 mm (0.05 in). Nozzle Schedule: Two 6", two 3", Two 1", one 0.75".
Type: Heat Exchanger
Subtype: Shell and Tube
Manufacturer: Atlas Industrial
Condition: Unused
Material: Carbon Steel
Heat Transfer Surface Area: 28.5 m² (307 ft²)
Orientation: Horizontal
Type BEM. Replacement shell, spare, no heads with the unit.
Shell Pressure: 10.3 bar (150 psi). Shell Temperature: 662 °C (1,200 °F). Shell Material: Carbon Steel. Tube Pressure: 10.3 bar (150 psi). Tube Temperature: 662 °C (1,200 °F). Tube Material: Carbon Steel. Tubesheet Material: Carbon Steel. Vacuum: Yes. Shell Diameter: 406.4 mm (16 in). Length: 3,600 mm (140.8 in). Tube Type: Straight Tube. Tube Number: 135. Tube Diameter: 19.1 mm (0.75 in). Tube Length: 3,600 mm (140.8 in). Tube Thickness: 0.08 mm (0.003 in).
