Used reactors for sale – versatile processing vessels for industrial applications
Highest-ranked available inventory for this selection.
Used reactors for sale – versatile processing vessels for industrial applications
Choose a subtype for a more focused set of listings.
Use this setting to include or exclude equipment with this feature.
Use this setting to include or exclude equipment with this feature.
Select one or more values to narrow the current listings.
Use this setting to include or exclude equipment with this feature.
Select one or more values to narrow the current listings.
Use this setting to include or exclude equipment with this feature.
Set a numeric threshold to narrow the matching listings.
Enter a keyword to match this specification.
Use this setting to include or exclude equipment with this feature.
Select one or more values to narrow the current listings.
Select one or more values to narrow the current listings.
Set a numeric threshold to narrow the matching listings.
Select one or more values to narrow the current listings.
Select one or more values to narrow the current listings.
Select one or more values to narrow the current listings.
Showing 25 of 665 matching Reactors. Search: "glass lined".
Auft # 37387 belt driven by LOHER 3.6 KW, 1715 RPM, 3/7.7-13.3A/60Hz/220-380 volt motor, ex proof (T3). Designed to German TUV standards. Reglassed in Romani by UGE 2001.
6,300 liter order number 60669 Pressure ratings: Internal -1/6 Bar @ -25/+200°C total volume 8,190 liters; Jacket rated -1/6 Bar @ -25/+200°C total volume 795 liters. Lined with glass WWG9115 With a top mounted drive with Burgmann mechanical seal type M462L-D20 and Burgmann Thermosyphon TS 2000 pneumatic bottom outlet valve, and solids dosing device,
MFR # 12269 Model SA-3000 Special three top lifting lugs, six leg couplings, four side wall lugs Shell=1 & 1/64", heads=1 & 1/64", jacket =5/8" PTE size 10 drive with an EX proof 20 HP motor and a dry seal. 36" main cover. 18" man way with pro ring and sight glass assembly with man way assist.
Shell rated 150/FV @ 450 degrees F. Conventional jacket 150/FV @ 450 degrees F with welded 2:1 elliptical heads Alloy mixer with dual tier agitation, lower is a CBT, upper is a PBT
contract number 400902 Standard: DIN-28136 pressure internal -1/6 bar@ -25/+ 200 degrees C (1180 liter), jacket 7 bar @ -25/+ 200 degrees C (228 liter), Glass type 3008 Lubrication tank type: AAA Motor type: Ex proof (T4) Hansen electrical motor
Order 60670
with the jacket chamber insulated and sheathed with 14Ga 316SS Manufacturer's number: 2516 Glass 3009 Manuf #: 2516. Head NB# 1755 Head rated for 150psi/FV @ 500 degree F Glass 3009 3 blade pitched turbine agitator Motor: driven by 2 hp,230/460 volt XP
Head rating: Head 12 psi/FV @ 450 degree psi certified by: Ceramic coating Co. Man Serial# 844219 Model# 09185KB28 Right angle driver Manufactured by Textron 2500 rpm (6:1) ratio Top material: Glass L2001 (R104) 6” handway Glass L2001 (R104)
With baffle.
Glass Type: 3315/Nucite Jacket Pressure Rating reduced to 105PSI w/ internal vacuum.
Used reactors play a vital role in manufacturing environments where control over chemical, thermal, or biological reactions is essential. Whether you’re scaling up active pharmaceutical ingredients, processing specialty chemicals, or conducting precision fermentation, IPP offers ready-to-ship reactors from 20 global plant sites. With more than 47 years of expertise, IPP maintains the world’s largest inventory of secondhand and surplus process equipment.
IPP stocks jacketed, glass-lined via its group company Universal Glasteel Equipment (UGE), pressure-rated, and sanitary reactors in a range of capacities and configurations. All systems are professionally inspected and available immediately for fast global delivery.
