Showing 25 of 81 matching Wiped/Thin Film Evaporators.
Short Path wiped film evaporator system with internal condensor
includes SS seperator tank
Rated 490 liter
20 liter in the jacket.
Top mounted rotor drive with a 3 kw, 50 Hz gear motor with mechanical seal on rotor.
Graphie wipers on rotor
Unit has a bolted bottom head with 2.7 SqM internal tube condenser, inlet and outlet for condensor in Bottom head. Evaporator has a side bottom discharge for product.
Vessel weight empty, 700 kg; motor and rotor 350 kg.
jacketed thin ‘filmtruder’ evaporator system,
internal pressure -1/3.2 bar @ 200 degrees C (3900 liter), top jacket 7 bar @ 200 degrees C (11 liter), straight side jackets 7 bar @ 200 degrees C (3 x 65 liter), bottom cone jacket 7 bar @ 200 degrees C (9 liter), built to TUV,
(3) 316L stainless steel jackets on straights side, coned bottom with 316L stainless steel jacket, 750mm diameter x 4850mm long 316Ti stainless steel (1.4571) rotor, rotor driven by a 45/54kw, 3/50/60/380-420/440-480 volt, 1475/1765 rpm motor via a reduction gearbox, mechanical seal, approx 850mm internal diameter, clamped flat top, bottom outlet with a pneumatic operated ball valve, evaporator mounted on carbon steel lugs and in a carbon steel structure, system includes: (1) 8.52 square meter 316L stainless steel (1.4404/1.4435) tube, head and shell vertical condenser, manufactured by Luwa SMS, fabrik #4826102, pressure tube side vacuum @ 55 degrees C (100 liter), shell 6 bar @ 90 degrees C (224 liter), (16) 44.5mm diameter x 2 x 4m long 316L stainless steel tubes, single pass, 324mm diameter 316L stainless steel shell, 4751mm overall length, 316L stainless steel tubesheets, (2) 316L stainless steel dished heads, mounted on lugs, (1) vacuum pump, (1) liquid separator
jacketed thin film evaporator with condenser
internal pressure -1/atmospheric @ 160/190 degrees C (735 liter)
jacket 12 bar @ 190 degrees C (105 liter)
450mm diameter x 4139mm long rotor, total height 5160mm
DeDietrich drive, belt driven by 7.5kw, 3/50/400 volt, 1440 rpm CE, Ex II2G Ex de IIC T4 Gb ATEX motor via a reduction gearbox, rotor type 'P' with flexible wiper blades, mechanical seal with lubricator, bottom of shaft sits in a bush, 316 stainless steel jacket on straight side only, evaporator has 3- clamped sections, 1= 584mm diameter x 1145mm long separator section and 2- 450mm diameter x 1495mm long scraper sections
(1) 316 stainless steel tube, head and shell vertical heat exchanger, (2) 316 stainless steel dished heads, mounted on lugs,
jacketed wiped thin film evaporator with column and condenser
pressure internal -1/3 bar @ 250/350 deg C (38ltr)
jacket 29.6/26.9 bar @ 250/350 deg C (6ltr)
s/steel jacket on straight side only, rotor belt driven by 1.5 kw 3/50/500 volt 710rpm Exd 3nG5 motor, Crane 109 mechanical seal, evaporator with
(1) 300mm diameter x 1.8m high 316L s/steel jacketed packed column, manufactured by Dynamite Nobel, fabrik #521, pressure internal: 13 bar + vak @ 200 deg C (140ltr), jacket: 8 bar @ 200 deg C (30ltr), internal coil 8 bar @ 200 deg C (2.5ltr), bolt flat top, weld dsihed bottom, 300mm diameter x 1020mm high packing section, Sulzer packing,
(1) 1.2 sqm 316L s/steel (1.4571) tube, shell and head vertical jacketed heat exchanger, pressure tube side: 6 bar @ 200 deg C (40ltr), shell side: 3 bar + vak @ 200 deg C (50ltr), jacket: 8 bar @ 200 deg C 925ltr), (34) 25mm diameter x 2mm x 2.5m long 316L s/steel tubes, shell 250mm diameter x 2140mm total length, (1) dished head, (1) flat bonnet head,
all parts are TUV certified
wiped film evaporator with carbon steel jacket
jackets 10 bar @ 185 deg C, carbon steel jackets on straight side
rotor speed 210 rpm, wiper blades with teflon lining, double mech seal on shaft
heated length 2120mm
wiper blades with teflon lining, double mech seal on shaft
rotor belt driven by 3.5 KW, 3/50/380 volt, 750 rpm, IP 44, Exe G3 motor
wiped thin film evaporator
with external condensor and seperator tank
rated 440 liter
With top mounted 3.7 KW, 50 Hz gear motor, mechanical seal on rotor, (4) blade rotor with wipers
With 2 SqM external 1.4435 SS spiral coil condenser, manufactured by Zurcher, Serial number 630, rated -1/2 bar @ -20 to 200 degrees C in vessel; -1/6 bar @ -20 to 200 degrees C in the coil. Vessel is 419mm diameter x 936mm tangent to tangent, with bolted dished top, dished bottom, and (2) bank of internal spiral condensing coil. Coil and tank are 1.4435 SS.
Rated vac int. Upper jkt rated 257 psi (17.5 Kg/cm2) @ 208 deg C, lower jkt rated 205 psi (14 Kg/cm2) @ 298 deg C.
10" btm cone, 8" dia x 24" long entrainment section
No motor, unit is setup for belt drive
No stand.
wiped thin film evaporator system
Rotafilm
straight side made up of (2) 1354mm long bolted sections, c/steel jackets on straight side and bottom cone, rotor direct driven by 3.6 kw, 3/50/380 volt, 1450 rpm gear motor, mechanical seal on rotor, (4) blade rotor with wipers
evaporator mounted lugs. system includes (1) 2 Sqm 1.4435 s/steel coil condenser, fabrik #645, shell pressure -1/2 bar @ -20/200 deg C, coil -1/6 bar @ -20/200 degs C, 419mm diameter x 936mm tangent to tangent shell, bolted dished top,weld dished bottom, (2) banks of internal spiral condensing coil. mounted on lugs, (1) 88ltr 1.4435 s/steel vertical separator tank with internal coil, fabrik #646, internal pressure -1/6 bar @ -30/300 deg C, coil -1/13 bar @ -30/200 deg C (4ltr), 280mm diameter x1m straight side
Jkt rated 13 bar @ 220 deg C
Shell 850mm (34") dia x 4800mm (15.8') long,
Rotor driven by 30 KW, 3/50/380 volt, 260 rpm output speed.
with 316 SS rotor,
Jacket rated for 218 psi at 482 degrees F.
Heating surface area 150.7 Sq. Ft.,
Serial numbers: Lower Body Serial Number 1400/56, National Board Number 717; Interm body Serial Number 1400/56, National Board Number 716; Upper Body Serial Number 1400/56, National Board Number 715; Lower cone Serial Number 1400/56, National Board Number 718.
Body is 850 mm inside diameter x 6320 mm to bottom of cone. Rotor assembly is 4 blade 316 SS construction, bottom cone is solid Hastelloy, shell is Hastelloy Clad. Unit driven by a 25 hp, 3 phase, 60 cycle, 230/460 volt motor, with Class 1 Group D label, Rotor speed is 880 rpm.
wiped film lab size evaporator system.
jacket 13.8 bar @ 200 degrees C. Consisting of (1) 2.5 square feet 304 stainless steel vertical jacketed wiped/thin film evaporator.
with 304 stainless steel jacket. 4-blade flexible teflon wipers. Rotor driven by Eurodrive, Type RGUV-031A, 30-177 rpm, 17.06:1 ratio, varispeed drive, driven by 3 KW, 3/50/415 volt, 1430 rpm flameproof motor. Mechanical seal. (1) stainless steel circulation pump. manufactured by Howard Pumps, serial #14037, model #CL2-20. Capacity 5000 liter/hour, pressure 6 bar. Eurodrive 98-381 rpm, 5.04:1 ratio, varispeed drive, driven by 7.5 KW, 3/50/415 volt, 1440 rpm flameproof motor. (1) approx 15 square feet stainless steel tube, head and carbon steel shell heat exchanger. manufactured by Johnsons, serial #63055. Pressure 163 psi @ 300 degrees C. Shell 7" diameter x 72" long. Shell with expansion bellows.
Shell rated at FV/16 psi at 662 degrees F.
jacket rated at FV/93 psi at 662 degrees
Sako Thin Film type.
Stainless steel rotor.
Requires 40 HP drive system.
jacketed conical wiped film evaporator,
capacity volume 1.480 liter, (2) jackets rated 20 bar @ 250 degrees C, capacity volume 11 liter and 53 liter
rotor direct driven by a 15 kW electrical motor, manufactured by Eberhard Bauer, type G52-10/D6A4-499, serial number 1759866-1, 3~/50Hz/500V/1460 rpm, EExeIIT3,
with hdraulic aggregat driven by a 0,55kW electrical motor, manufactured by Loher, type DNGW-080BG-04E, serial number 2287901H, 3~/50Hz/500V/1.395rpm, EExdeIICT4.
Short Path wiped film evaporator system with internal condensor
includes SS cold trap. Rated 490 liter
20 liter in the jacket
Top mounted rotor drive with a 1.5 kw, 50 Hz gear motor with mechanical seal on rotor, graphit wipers on rotor.
.2.7 SqM internal tube condenser, inlet and outlet for condensor in Bottom head. Evaporator has a side bottom discharge for product.
Vessel weight empty, 700 kg; motor and rotor 350 kg.
304 ELC SS 40% clad on Carbon steel (for product contact),
thin film evaporator system
Mfd by Buflovak
165 psi @ 400 deg F jkt.
NB stamped 5931. Rotor was under driven by 20 HP, 3/60/220/440 volt mtr w/UL label, 480 rpm rotor speed. (motor for drive not available). Unit has external upper & lower bearings, mech seals on shaft. Unit has 3" feed port and 10" x 24" discharge into centrifugal vapor/liquid separator.
36" deep cone btm.
W/system is 565 sq ft, 304LSS shell side, CS head, horiz condenser with 3/4" OD x 18 bwg, 304LSS tubes, 143" long. 6 pass tube side. 18" dia 304ELC SS shell 161" overall length. CS channels. Unit designed for 30 psi & full vac @ 400 deg F shell side; 100 psig @ 400 deg F tube side. Openings: shell 1-10", 1-3"; channels 2-4" one head, (2) 3/4" other head. Mfd by Patterson Kelly. Also w/unit is an 81 sq ft aftercondenser. Mfd by Graham, 304SS shell side, CS tube side. Unit rated 50 psig/full vac @ 150 deg F shell side; 75 psig @ 150 deg F tube side. Asme code constructed. 8" dia shell, 8' long tubes, 9'11" overall length.
304 ELC SS 40% clad on Carbon steel (for product contact),
thin film evaporator system
165 psi @ 400 deg F jkt
NB stamped 5932. Rotor was under driven by 20 HP, 3/60/220/440 volt mtr w/UL label, 480 rpm rotor speed
Unit has external upper & lower bearings, mech seals on shaft. Unit has 3" feed port and 10" x 24" discharge into centrifugal vapor/liquid separator.
36" deep cone btm
W/system is 565 sq ft, 304LSS shell side, CS head, horiz condenser with 3/4" OD x 18 bwg, 304LSS tubes, 143" long. 6 pass tube side. 18" dia 304ELC SS shell 161" overall length. CS channels. Unit designed for 30 psi & full vac @ 400 deg F shell side; 100 psig @ 400 deg F tube side. Openings: shell 1-10", 1-3"; channels 2-4" one head, (2) 3/4" other head. Mfd by Patterson Kelly. Also w/unit is an 81 sq ft aftercondenser. Mfd by Graham, 304SS shell side, CS tube side. Unit rated 50 psig/full vac @ 150 deg F shell side; 75 psig @ 150 deg F tube side. Asme code constructed. 8" dia shell, 8' long tubes, 9'11" overall length.
Mfd by Balfour/Sybron
Order #48621
Lined w/glass #3115
CS jkt 98 psi @ 392 deg F
Has glass covered int rotor w/graphite wipers. Retaining pins and rotor shaft are titanium.
jkt body section, 48" dia x 9'10" str side; and clamp jkt cone btm.Has 3-sections: clamped dish entrainment section, 48" dia x 42" str side; jkt body section, 48" dia x 9'10" str side; and clamp jkt cone btm.
Drive is Pfaudler Type VS80-U21983, belt driven by approx 10 HP motor w/mech seal on shaft.
(Two SPDU's)
product contact, complete Short path distillation plant.
This unit was previously used to process 300 lbs/day of product.
The system consists of two, 0.1 m2 short path distillation units, three cold traps, six hold up receivers, and a degassing column with a pre heater.
All equipment is piped and mounted in a steel framework, including all pumps, vacuum pumps, heater, valves, and controls.
This process system has the following attributes: Can operate up to 340 degrees C, It is capable of vacuum to 0.01 mbar. , has a short resonance time, is good for heat sensitive products and hazardous materials, is suitable for viscous products, and has an excellent turn down capacity.
Product contact surfaces are finished to 0.62 um RA
The process piping and hold up tank are jacketed.
The cold traps feature double coils for hot and cold brine.
The system includes all process pumps and vacuum pumps.
Primary and secondary heaters are supplied by Sterling.
Chillers are supplied by Micro Therm.
Short Path wiped film evaporator system with internal condensor
includes SS seperator tank. Rated 2000 liter
95 liter in the jacket.
Top mounted rotor drive with a 3.7 kw, 50 Hz gear motor with mechanical seal on rotor, Graphite wipers on rotor.
Evaporator has a side bottom discharge for product.
Vessel weight empty, 2600 kg; motor and rotor 800 kg.
Short Path wiped film evaporator system with internal condensrr
includes SS seperator tank
Rated 2000 liter
95 liter in the jacket. Top mounted rotor drive with a 3.7 kw, 50 Hz gear motor with mechanical seal on rotor, graphite wiper on rotor.
Evaporator has a side bottom discharge for product.
Vessel weight empty, 2600 kg; motor and rotor 800 kg.
Short Path wiped film evaporator system with internal condensor
includes SS seperator tank
Rated 2000 liter
95 liter in the jacket. Top mounted rotor drive with a 3.7 kw, 50 Hz gear motor with mechanical seal on rotor, Graphite wipers on rotor.
Evaporator has a side bottom discharge for product.
Vessel weight empty, 2600 kg; motor and rotor 800 kg.
jkt rated 125 psi @ 350 deg F 2-zone CS jkt.
10' long evaporation section. 8-blade rotor,
mech seal on shaft.
Belt driven by 30 HP, 3/60/460 volt, 890 rpm TEFC motor.
jkt rated 16 kg/sq cm @ 200 deg C.
9 gal capacity
W/(2) rows of str blades and (2) rows of positive pitched blades @ 25 deg angle on central core. Driven by 20 HP, 1170 rpm Reeves variable speed drive, 6.2:1 ratio, 64 rpm min, 428 rpm max. C-configuration. Has air operated valve positioner w/mech seal.
Has jkt btm cone; rotor extension (removable product propelling rotor section).
Used evaporators are thermal separation systems that concentrate solutions, recover solvents, or reduce waste volume by vaporizing liquid components. These systems are essential across industries where product purity, yield, and cost-efficiency matter. With more than 47 years of industry expertise, IPP offers used, secondhand and surplus evaporators from 20 complete plant sites and a massive inventory of over 15,000 systems ready to ship.
Evaporators are available in multiple configurations—falling film, rising film, forced circulation, wiped film and multiple-effect systems—each tailored for specific viscosity, temperature sensitivity and throughput needs.
Evaporators are built for long service life, cleanability and chemical resistance:
