pressure both sides -1/10 bar @ -50/150 degrees C (18 liter/17 liter) fully insulated, CE-0036,

side A = 550 ltr, side B = 570ltr

Rated FV/300 psi @ -20 to 425 degrees tube side; FV/50 psi @ -20 to 425 degrees F shell side.
with glass lined clamped heads Tube Number: 18. Tube Diameter: 0.8 in. Tube Length: 216 in.

• Cooling water lines: two 8" lines. 2 pass design Tube Type: Straight Tube. Tube Number: 250. Tube Diameter: 1.3 in. Tube Length: 192 in. Tube Thickness: 0.1 in. Nozzle Schedule: - Inlet: 18" vapor inlet - Outlet: 4" vapor outlet.

2-stage (2) 450 Sq Ft condensers bolted together, end to end, with same configuration and material in both stages, Upper stage and lower stage each have a 316LSS shell, CS heads. Shell is 0.135" thick, Heads are 1.12" thick CS. Spiral Material: Stainless Steel 316.

AL6XN channel heads with R-Stamp(1994) Tube Diameter: 1.3 in. Tube Length: 144 in. Tube Thickness: 0 in. Nozzle Schedule: - Nozzle Schedule: - Two 32" tube side nozzles (brine inlet & outlet) - One 18" steam inlet - One 4" condensate outlet - One 3" drain - Two 1" drain/vents.

tube pressure rated by -1/10bar @-10/200 degrees C (volume 66 liter), shell pressure rated by -1/10bar @ -10/200 degrees C (volume 180 liter) Length: 188.5 in. Shell-side Passes: 1. Tube-side Passes: 1. Tube Type: Straight Tube. Tube Number: 121. Tube Diameter: 0.6 in. Tube Length: 165.4 in. Tube Thickness: 0.1 in. Nozzle Schedule: shell side: (1) DN100, (2) DN200, (1) DN300; tube side: (1) DN150, (1) DN200. Capacity: 65 gallons. Heat Exchanger Tube Capacity: 17.4 gallons.

• Type: Horizontal graphite spiral block heat exchanger
• Weight: 210 KG Product Side -1/3 bar@ -20 to +165 degrees C 17 liters

(2) 300mm high cone sections,

Heads are CS faced with 316 L SS Spiral Material: Stainless Steel 316L.

Process sidde rated 45 PSI @ -30/+122 degrees F. Service side rated 30 PSI @ -30/+122 degrees F.

cubic block heat exchanger process side is 2-pass with (2160) slots, 9.5mm x 3mm, service side is multi-stage with (756) 9.5mm diameter tubes can be used vertical or horizontal.

319.5m² compabloc 1.4404 stainless stell plate and carbon steel frame Compabloc heat exchanger, manufactured by Alfa Laval, serial number CP75-5479, Side A pressure rated by -1/15bar @ -10/250 degrees C (volume 1180 liter), Side B pressure rated by -1/15bar @ -10/250 degrees C (volume 1185 liter), (500) 1.4404 stainless steel plates, openings: Side A (2)DN200, (1)DN25 drain, (1)DN25 vent; Side B (2)DN200, (1)DN25 drain, (1)DN25 vent.

With Badger expansion joint. TEMA type BEM 10-4-96. Length: 92 in. Shell-side Passes: 1. Tube-side Passes: 4. Tube Type: Straight Tube. Tube Number: 160. Tube Diameter: 0.5 in. Tube Length: 96 in. Nozzle Schedule: Four 3” nozzles..

Titanium/321 (1.4401) stainless steel plate heat exchanger, pressure side 1 -1/6 bar @ -20/150 degrees C (32 liter), side 2 -1/6 bar @ -20/150 degrees C (33 liter), plate material side 1 321 (1.4401) stainless steel, side 2 Titanium,

Power: 85 kW 85 kw, pressure tube side -1/4.5 bar @ 200 degrees C (110 liter), shell -1/6 bar @ -20/50 degrees C (90 liter) 316Ti (1.4571) stainless steel shell with expansion joint (1) 316L (1.4435) stainless steel bonnet head, (1) 316L (1.4435) stainless steel dished head, TUV certified. Tube-side Passes: 1. Tube Number: 480. Tube Diameter: 0.5 in. Tube Length: 63 in. Nozzle Schedule: Openings: Tube side: bonnet head with 1-200mm, 1-50mm, dished head with 1-200mm - Shell: 2-80mm.

Internal plate coil baffle heaters(double)

• Internal plate coil baffle heaters (double)

design pressure tube side -1/6 barg @ -25/200 degrees C (198 liter), shell 0/16 barg @ -25/200 degrees C (123 liter), (126) 25.4mm diameter x 1.65 x 2002mm long, 417mm diameter 316L stainless steel (1.4404) shell with expansion joint, (16) 316L stainless steel (1.4404) internal baffle plates, (2) Hastelloy C22 (2.4602) integral channel heads with Hastelloy C22 clad removeable end plates Length: 110.2 in. Tube Type: Straight Tube. Tube Number: 126. Tube Diameter: 1 in. Tube Length: 78.8 in. Nozzle Schedule: tubes side 1 head with 1-250mm, 1 head with 1-75mm, shell 2-100mm. Capacity: 32.5 gallons. Heat Exchanger Tube Capacity: 52.3 gallons.

• Internal plate coil baffle heaters

• Internal plate coil baffle heaters

Heat exchanged: 220 kw single pass both sides Flow rate (process side): 240 m3/hr Flow rate (service side): 63.31 m3/hr Inlet temperature (process side): 28 deg C Inlet temperature (service side): 24 deg C Outlet temperature (process side): 27.3 deg C Outlet temperature (service side): 27 deg C

Heat exchanged: 220 kw single pass both sides

• Flow rate process side: 240 m3/hr
• Flow rate service side: 63.31 m3/hr
• Inlet temperature process side: 28 deg C
• Inlet temperature service side: 24 deg C
• Outlet temperature process side: 27.3 deg C
• Outlet temperature service side: 27 deg C

pressure tubeside 9 bar @ 180 degrees C (318 liter) shell -1/1 bar @ 180 degrees C (555 liter) 5mm thick 316Ti (1.4571) stainless steel shell (2) 316Ti stainless steel dished heads Tube-side Passes: 1. Tube Number: 76. Tube Diameter: 2.1 in. Tube Length: 63 in. Tube Thickness: 0.1 in. Nozzle Schedule: openings tube side:1-head with 1-300mm, 1-head with 1-150mm, shell: 2-125mm.

• Internal plate coil baffle heaters
