Type: Reactor

Subtype: Batch-Type Agitated

Manufacturer: Pfaudler

Model: BE

Condition: Used

Material: Glasslined

Capacity Design: 8,190 L (2,164 gallons)

Internal Pressure: 6 bar (87 psi)

6,300 liter order number 60669 Pressure ratings: Internal -1/6 Bar @ -25/+200°C total volume 8,190 liters; Jacket rated -1/6 Bar @ -25/+200°C total volume 795 liters. Lined with glass WWG9115 With a top mounted drive with Burgmann mechanical seal type M462L-D20 and Burgmann Thermosyphon TS 2000 pneumatic bottom outlet valve, and solids dosing device,

Internal Full Vacuum: Yes. Internal Temperature: 200 °C (392 °F). Jacket Pressure: 6 bar (87 psi). Jacket Temperature: 200 °C (392 °F). Orientation: Vertical. Agitation: Yes. Diameter: 2,000 mm (78.7 in). Straight Side Length: 3,268 mm (128.7 in). Support Type: Lugs.

Type: Filter

Subtype: Rosenmund and Cogiem

Manufacturer: 3V Cogeim

Model: Filtodry FPP XD 400 FM

Condition: Used

Material: Hastelloy - C22

Filtration Area: 4.2 m² (44.7 ft²)

Diameter: 2,300 mm (90.6 in)

Alloy C22

Internal finish is a sanitary polish. 304SS sheathing. 304 stainless steel

18.35" Side discharge with discharge valve, 132 gallon Hastelloy C 22 side discharge valve. National Board # 287. rated FV/88 @392 degrees F.

Dryer Dimensions: 90" diameter x 76" length

hydraulic skid. Includes: integral Stock # 241013- Hastelloy C22 pulse jet Dust collector. 8.6" handhole, 4.33" site glass.

Pressure: 6.1 bar (88.5 psi). Temperature: 200 °C (392 °F). Jacket: Yes. Jacket Type: Half Pipe/Limpet. Jacket MOC: Stainless Steel 316. Jacket Pressure: 10.5 bar (152 psi). Jacket Temperature: 200 °C (392 °F). Agitator Cored for Heating/Cooling: Yes.

Type: Dryer-Porcupine

Manufacturer: Bethlehem Corp

Model: 1P1203

Condition: Used

Material: Stainless Steel Other

Shell Configuration: Trough

Operational Mode: Batch

• REBUILT 2.1 cu. ft. operating capacity Jacketed Porcupine Processor designed for batch operation manufactured by Bethlehem Foundry and Machine Company
• Shell is rated for MAWP 50 PSI
• Porcupine surface area is 15 sq. ft jacket is 9.4 sq. ft Head flats are 3/4" and 3 & 7/8"shell is 1/4" and jacket is 5/16"
• 230/460 volt motor with a Renoylds reduction gear

5 CFRT

with a 207:1 ratio Steam or hot oil inlets and outlets are all 1" NPT Process inlets an are two 3" and outlets are 3.5"

• Rebuilding included the following: Unit is stripped, cleaned, and shaft and jacket pressure tested Gearbox drained, cleaned, checked and refilled. Motor replaced, unit test run. Stuffing box gaskets replaced and new rotary joint installed. New top head cover gasket replaced, Test run and painted, new coupling guard installed.

Diameter: 304.8 mm (12 in). Length: 914.4 mm (36 in). Number of Shafts: 1. Has Jacket: Yes. Jacket Surface Area: 0.87 m² (9.4 ft²). Porcupine Surface Area: 1.39 m² (15 ft²). Porcupine Operating Pressure: 10.3 bar (150 psi). Porcupine Operating Temperature: 315.6 °C (600 °F). Jacket Operating Pressure: 10.3 bar (150 psi). Jacket Operating Temperature: 315.6 °C (600 °F). Total Heat Transfer Surface Area: 2.3 m² (24.4 ft²).

Type: Compressor

Subtype: Rotary

Manufacturer: Sullair

Model: LS-10-30 WCWC

Condition: Used

Compressor Type: Rotary

Discharge Pressure: 8.6 bar (125 psi)

115 to 125 max. psi Rotary Screw Air Compressor Oil Free, packaged design, with microprocessor controls, cooler and lubricator

Flow Rate: 186.9 m3/h (110 CFM). Oil Free: Yes.

Type: Heat Exchanger

Subtype: Spiral

Manufacturer: Alpha Laval

Model: 3-6

Condition: Used

Material: Stainless Steel 316

Heat Transfer Surface Area: 83.6 m² (900 ft²)

Shell Pressure: 2.6 bar (37 psi)

2-stage (2) 450 Sq Ft condensers bolted together, end to end, with same configuration and material in both stages, Upper stage and lower stage each have a 316LSS shell, CS heads. Shell is 0.135" thick, Heads are 1.12" thick CS.

Shell Temperature: 232.2 °C (450 °F). Shell Material: Stainless Steel 316L. Shell Diameter: 1,194 mm (47 in). Head Material: Carbon Steel. Length: 1,270 mm (50 in). Nozzle Schedule: Openings include: (2) 4" shell side in each stage; (2) 4" service side.. Cold-side Pressure: 2.6 bar (37 psi). Cold-side Temperature: 232.2 °C (450 °F). Hot-side Pressure: 2.6 bar (37 psi). Hot-side Temperature: 232.2 °C (450 °F). Spiral Material: Stainless Steel 316.

Type: Reactor

Subtype: Batch-Type Agitated

Manufacturer: Stalwart International

Condition: New

Material: Stainless Steel 316L

Capacity Design: 15,142 L (4,000 gallons)

Internal Pressure: 10 bar (145 psi)

UNUSED

Internal finish 240 grit buff polished-Bright polished, external buff polish to a matte finish. ASME NB rated, and "U" stamped.

welded dish heads (2:1) 12 mm thick

Coil: 114 mm OD x 4 mm thick,

Limpet covers bottom dish and 2615 mm of straight side (pitch 150mm). Coil heating surface area.

With Insulation rings and upper drip ring. Two top lifting lugs and one tailing lug.

20" Manhole with Cover and davit arm assist, one 6" sight glass,

Internal Full Vacuum: Yes. Internal Temperature: 150 °C (302 °F). Sanitary Construction: Yes. Jacket Pressure: 10 bar (145 psi). Jacket Temperature: 150 °C (302 °F). Jacket Material of Construction: Stainless Steel 304. Orientation: Vertical. Agitation: Yes. Diameter: 2,450 mm (96.5 in). Straight Side Length: 3,150 mm (124 in). Support Type: Lugs.

Type: Reactor

Subtype: Batch-Type Agitated

Manufacturer: DeDietrich

Model: SA

Condition: Used

Material: Glasslined

Capacity Design: 11,356 L (3,000 gallons)

Internal Pressure: 6.9 bar (100 psi)

MFR # 12269 Model SA-3000 Special three top lifting lugs, six leg couplings, four side wall lugs Shell=1 & 1/64", heads=1 & 1/64", jacket =5/8" PTE size 10 drive with an EX proof 20 HP motor and a dry seal. 36" main cover. 18" man way with pro ring and sight glass assembly with man way assist.

Internal Full Vacuum: Yes. Internal Temperature: 204.4 °C (400 °F). Jacket Pressure: 6.2 bar (90 psi). Jacket Temperature: 204.4 °C (400 °F). Orientation: Vertical. Agitation: Yes. Diameter: 2,489 mm (98 in). Straight Side Length: 1,930 mm (76 in).

Type: Evaporator

Subtype: Crystalizer/Evaporator

Condition: Used

Material: Rubberlined

Clad: Yes

Evaporation Rate: 9,072 kg/h (20,000 lb/h)

Diameter: 4,877 mm (192 in)

CS, with rubber lining, Vapor Body, with Alloy support accessories, forced circulation crystallizer, part of a Zero Discharge System (ZLD). The system's major equipment consists of a shell and tube evaporator heater, Vapor body, recirculation pump and centrifuge. Rated for 50 GPM flow 10% moisture) and consumes 20 psi steam at 25,00 lbs./hr Following is a short process description: The feed from Brine Evaporator enters the recirculation piping above the recirculation pump. The feed is mixed with recirculating brine slurry and pumped through the heater where it increases in temperature and is sent to the vapor body. The hot brine flashes down to the saturation pressure inside the vessel, producing vapor and the cycle is repeated. Crystals are formed continuously in crystallizer vapor body and have to be removed. Concentrated product is removed from the system, passed through a centrifuge to remove the solid crystals and is returned to the evaporator recirculation line. The crystals are sent to a landfill. Vapor from the crystallizer is sent to a small barometric condenser using cooling water to condense the vapors. Condensate is mixed with incoming cooling water and is discharged back to the cooling tower. Vent from the condenser is vented by a CS ejector, through a silencer, and out to the atmosphere. Prime condensate from the condensed plant stream is sent back to the primary feed heater to assist in heating incoming Brine Evaporator feed. The following are main components of the system: Stock #228100- crystallizer heater is 5,700 Ft2 of surface area, with 1040 straight tubes, 1.25”OD x 0.028” wall thickness x 12 Feet long, and are constructed of Titanium. The tube sheets are SS316 Ti clad. Heads are made of SS alloy AL6XN & Shell of SS316L. The Crystallizer stock # 228156 is 16’ Dia. x 30’ Overall Height with 60” cone bottom. It is made of rubber lined Carbon steel. (the crystallizer vessel was removed , we have a drawing so a new vapor body can be constructed.) The Crystallizer recirculation pump, stock #228104 is 19,000 GPM with 150 HP motor and fabricated from SS alloy. The centrifuge stock #228101 is Bird Bowl type, 24" diameter x 38" long, rated for 18,304 Lbs./hr. with SS316L contact parts, 30 HP Motor with SS alloy product contact parts.
